Home > Products > Dosing and Mixing > CE Standard Made in China Superior Quality Stainless Steel Industry Plastic PVC PE PET Gravimetric Batch Doser Blender
CE Standard Made in China Superior Quality Stainless Steel Industry Plastic PVC PE PET Gravimetric Batch Doser Blender
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Liansu CE Standard High Quality Asymmetrical Hopper Single Screw Power Loss In Weight Feeder
-
Liansu CE Standard High Accuracy Automatic Single Screw Volumetric Feeder Loss in Weight Feeder System
-
PLC Control Industry Plastic Mixer Gravimetric Batch Vertical Blender
-
High Quality Factory Hot Selling Weighing Gravimetric Blender Plastic Machine
-
Good Quality Automatic Vacuum Hopper Loader for Plastics Volumetric Feeder and Powder Granule Loss in Weight Feeder System
-
Liansu CE Standard Factory Sale Plastic Pellets Granules Vertical Plastic Weigh Mixing Machine
Product Description
Features:
* PLC control, touch screen display, easy to operate and understand;
* Modular assembly structure, convenient disassembly and assembly, easy to clean and exchange;
* All materials are uniformly mixed by gravity measurement, and the micro-metering accuracy can be strictly controlled within the scope of ±0 5%;
* Automatic repeated calibration function, which automatically calibrates the program after each weighing to ensure the highest dosing accuracy;
* With the formula storage function, up to 100 formulas can be stored;
* With the alarm history function;
* With Ethernet communication function, realizing networking with the molding machine and centralized monitoring function.
Working principle:
* When the metering valve is started, the hopper metering valve opens according to the time value calculated by the preset weight value and the unit feeding volume of the metering valve. When the feeding time is up, the metering valve closes and the weighing pan is checked. If within the specified error range, it goes to the next hopper for weighing and check;
* When the raw materials in all the hoppers have been weighed and checked, they will fall into the mixing bucket for stirring and mixing. When the mixing time is up, they will be automatically discharged into the bottom storage hopper.
Scope of application:
* Equipped with a magnetic base, it can be directly installed on the injection molding machine/extruder;
* Equipped with a weighing machine support and material distribution station, it can be connected to the feeding system.
Specification table:
Model | Maximum processing capacity (kg/hr) | Batch processing capacity (kg) | Stirring motor (kw) | Compressed air (bar) | Number of hoppers | Number of screw rods | Voltage | |||||||
LSGB-200-4-R1 | 200 | 3 | 0.15 | 4-6 | 4 | 1 | 3¢, 380V, 50Hz | |||||||
LSGB-600-4-R1 | 600 | 10 | 0.55 | 4-6 | 4 | 1 | 3¢, 380V, 50Hz | |||||||
LSGB-1200-4-R1 | 1200 | 20 | 1.1 | 4-6 | 4 | 1 | 3¢, 380V, 50Hz | |||||||
LSGB-2000-4 | 2000 | 30 | 1.1 | 4-6 | 4 | / | 3¢, 380V, 50Hz | |||||||
LSGB-3000-4 | 3000 | 50 | 1.5 | 4-6 | 4 | / | 3¢, 380V, 50Hz | |||||||
LSGB-5000-4 | 5000 | 90 | 2.2 | 4-6 | 4 | / | 3¢, 380V, 50Hz | |||||||
Note: The above models are equipped with a support + storage hopper + material distribution station; PLC control, touch screen display; Siemens weighing sensor; The above models are only suitable for 3-6mm granules | ||||||||||||||
Product structure display
Case display
CLICk HERE TO START OUR 3D SHOWROOM
VR
