Product Price: 5.03-15.1 USD/tablet
Color: Red, blue, green, yellow, customizable
Minimum Quantity: 1*20GP
Product Delivered Quantity: 500
Application: Construction, Engineering
Material: Q235 Steel, Q355 steel
Surface Treatment: Flame Plating/ Electro galvanized
Size
Kwikstage Scaffolding System upright tube | |||
Ledger(P.G.)(H.D.G.)mm | Size(mm) | KG(H.D.G) | KG(P.C) |
48.3*3.25 | 500 | 3.63 | 3.53 |
48.3*3.25 | 1000 | 6.56 | 6.37 |
48.3*3.25 | 1500 | 9.48 | 9.21 |
48.3*3.25 | 2000 | 12.4 | 12.02 |
48.3*3.25 | 2500 | 15.33 | 14.86 |
48.3*3.25 | 3000 | 18.25 | 17.7 |
Kwikstage Scaffolding System cross bar | |||
STD/Ledger(P.G.)mm | Size(mm) | KG(H.D.G) | KG(P.C) |
48.3*3.25 | 500 | 2.87 | 2.79 |
48.3*3.25 | 700 | 3.58 | 3.48 |
48.3*3.25 | 800 | 3.76 | 3.66 |
48.3*3.25 | 1000 | 4.44 | 4.31 |
48.3*3.25 | 1200 | 5.39 | 5.24 |
48.3*3.25 | 1800 | 7.38 | 7.17 |
48.3*3.25 | 2400 | 9.54 | 9.27 |
Kwikstage is a kind of modular scaffolding system, which is versatile and serves various purposes. This kind of scaffolding system is highly useful in situations where the facade of the building is complex, and a regular facade scaffold cannot be positioned. Kwikstage Scaffolding System is high, convenient disassembly, weighing capacity, functional diversity, star type scaffold standard connection point for 4 high strength steel plate stamping triangle iron.
The two ends of the Kwikstage Scaffolding System are welded with oblique iron, the cross plug and the steel pipe contact range is large, with a two-way locking function, can effectively improve the overall strength and safety of the star scaffold, better meet the construction safety.
Introduction to kwikstage scaffolding
kwikstage scaffolding is a modular scaffolding system with a wide range of uses and applications. This scaffolding system is very useful in situations where the complexity of the building façade makes it impossible to locate conventional façade scaffolding.
The best thing about modular scaffolding, such as kwikstage, is that it can be moulded into any shape to suit the structure of the building. The kwikstage can also be flexibly installed on either side of the building façade in order to make the project as simple as possible.
The kwikstage scaffolding combines various individual components that can be flexibly interconnected to build the most suitable scaffolding for the project. The individual components are also easier to stack, transport and connect. Due to the lack of loose components, the rapid stage scaffolding stays in place and has a stable vertical alignment. This makes kwikstage scaffolding a safe scaffolding system that workers can use with confidence.
Thanks to these effective properties, kwikstage scaffolding can support the creation of unique building structures and is becoming increasingly popular in the engineering and construction sector.
Benefits of kwikstage scaffolding
kwikstage scaffolding is modular, which means that it is highly versatile and can be changed as required to suit different purposes. This type of system is particularly useful where building elevations are not uniform and make traditional scaffolding systems impractical.
VersatilityInclusivity and versatility
Rapid stage kwikstage scaffolding is designed to be easily adaptable to different situations and to suit a variety of applications. It has a wide variety of components that allow kwikstage scaffolding to help set up various structures and in turn help build a stunning building. In most cases, the basic components of the Quick Stage are sufficient; just a few additional components are needed to help kwikstage scaffolding become more adaptable to the situation. The main use of modular kwikstage scaffolding is that it allows the platform to be changed to suit different shapes and thus to access certain structures more easily. The kwikstage scaffolding consists of several modular components that allow the platform to be easily modified to suit the project. kwikstage scaffolding is designed for a variety of uses, but is mainly used for central compartments and supporting floors. As mentioned earlier, the Quick Stage is able to mould itself into the shape of the structure being built, which is why it does not create any complications when building arches, angles or oriented bridges. It is used for formwork and construction. kwikstage scaffolding has been expressly designed to adapt to different situations and to the changing needs of contemporary job sites, where work done at height becomes more and more delicate every year. Workers need a system that is safe, flexible and easy to use - and this product meets those needs.
Applications
Its adaptability and speed of installation allows it to be used in a wide range of applications from house building to large industrial applications, from towers to platforms, as well as for general purpose and inspection in light or heavy access.
About us
With a wide range of accessories including handrails, board stage-brackets, staircase towers and loading bays, we provide safe and secure access systems for all requirements.
We also offer an export service on kwikstage to anywhere in the world, which can be arranged by a member of our sales team.
Shop quality kwikstage scaffolding? Choose ZHONGHONG! As a kwikstage scaffolding manufacturer,kwikstage scaffolding wholesale,kwikstage scaffolding factory, we can produce scaffold as heavy-duty kwikstage scaffolding as you hoped, Also It is much more reasonably wholesale priced than any of the competitors. Buy kwikstage scaffolding for many things. we provide fast and knowledgeable service of kwikstage scaffolding. Come for any other scaffolding or accessories that you might be in need of in the future. Contact us ! The contact email is rdzhonghong88@gmail.com.
