Die Slitting Rewinder Printed Film Roll to Sheet Paper Cutting Machine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

Technical parameters:

Item Number	DP-360CQ	DP-500CQ	DP-600CQ
Web Width	0-360mm	0-500mm	0-600mm
Cutting length	0-9999.99mm	0-9999.99mm	0-9999.99mm
Cutting speed	0-130 cut/min	0-130 cut/min	0-130 cut/min
Cutting precision	±0.05mm	±0.05mm	±0.05mm
Voltage	220V/380V	220V/380V	220V/380V
Size	12809201300mm	128011501070mm	150013001200mm
Weight	240kg	270kg	320kg
Total Power	1.5kw	1.5kw	1.5kw

*the voltage can customize according to your country standards.

Features:

Taiwan brand servo motor & Japan brand mitsubishi PLC;

Touch screen control panel,easy to operate;

Can preset and adjust the cutting length ,total cutting quantity and speed;

Afer the machine shutting down,it still can remember the amount automatically;

Cutting tolerance can be reach ±0.1mm based on material;

Optional function:
Kiss cut (half-cut)

Hot cutting

Static electricity eliminator

Cutting with position sensor

Application:

Sizing cutting for conductive fabric, foam , diffuser, reflector film, double-sided adhesive tape, nickel plate, PET,PC,PE insulation paper, copper /aluminum foil and all kinds of adhesive tapes.

Optional Devices

Kiss cutting

Material:Utility knife and fixture

This unit can finish kiss cutting .Below anvil is connected with springs,which could absorb shock and make sure the kiss cutting well.Easy to adjust and maintain.

Photo sensor

If added photo sensor for cutting machine,it can cut thr printed material.the photo sensor will sense the printed marking and make sure the cutting blade cut the material at a specified place.

ANTISTATIC SYSTEM

BEFORE AND AFTER THE CUTTING BLADE CAN ADD THE ANTI-STATIC SYSTEM

ANTI-STATIC SYSTEM MOTOR

After Sales Service

Free sample testing and video for your reference
Prompt delivery whthin 24 hours
One year warranty ,whole life technical support
Free training in our factory available before delivering machines
Engineers available to service machinery overseas
Technical support: Professional engineers team to help you design a drawing of machine to get highest profit with lowest cost and offer you technical support any time.
Other demanded spare part or equipment support: Plenty of cooperated professional supplier for spare parts or other necessary equipments make it possible for us to offer our customers big convenience to complete their production line in high quality with low cost in a short time.

Paper Cutting Machine
Die-cutting Machine
Slitting Rewinder
Paper Folding Machine
PUNCHING MACHINE

BUYING GUIDE

If you want to ask for quotation ,please tell us details information as much as you can ,so we can quote to you as soon as possible .

Material	Pictures are appreciated if possible
Diameter	ID & OD
Thickness	mm
Weight	KG
Length you want to cut	mm
Width	mm
