Home > Products > NDT Instrument > Factory Price Multi-Function Concrete Rebar Detector Metal Locator Scanner
Factory Price Multi-Function Concrete Rebar Detector Metal Locator Scanner
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Best-selling Rebar Metal Detector Rebar Scanner Covermeter
-
Metal Detectors Rebar Location Diameter Detection Concrete Rebar Detector Scanner Cheap Price
-
High Quality Concrete Rebar Detector Concrete Metal Rebar Detector for Sale
-
Basic Model Rebar Locator and Cover Meter of Pocket Type
-
Rebar Detector/Metal Detector Location in Concrete
-
Pocket Concrete Rebar Detector Steel Bar Scanner
Product Description
Factory price Multi-Function Concrete Rebar Detector Metal Locator Scanner
Usage Overview
The rebar locator is a portable non-destructive testing instrument,which can used for the detection of the construction quality of
reinforced concrete structures.it can measure the position of steel bars on the concrete surface and detect the thicknee of
thickness of the protective layer of the steel bars and diameter of the steel bars
reinforced concrete structures.it can measure the position of steel bars on the concrete surface and detect the thicknee of
thickness of the protective layer of the steel bars and diameter of the steel bars
Product Description
· Integral design, compact size
· Easy to carry and make work efficient
· Measurement data can be calibrated manually
Specification
Applicable range of protective layer thickness(mm) | Φ6mm~Φ50mm | |||||||
Host parameters | Large capacity lithium battery | |||||||
Maximum error of diameter indication | Graphic and digital display | |||||||
Maximum Allowable Error of Second Range Protective Layer Thickness | ||||||||
±1mm | 6~79mm | |||||||
±2mm | 80~119mm | |||||||
±4mm | 120~139mm | |||||||
±6mm | 140~200mm | |||||||
Power supply mode | ||||||||
Waterproof parameters | IP65 | |||||||
Screen size | 5 inches | |||||||
Resolving power | 320*240 | |||||||
Volume | 195*140*45mm | |||||||
Weight | 0.8kg | |||||||
Working environment requirements | ||||||||
Temperature | -10℃~+40℃ | |||||||
Humidity | <90%RH | |||||||
Unpacking display
Our Advantages
1.Upgraded wireless cloud transmission function
2.Adopt three anti-shell design, waterproof, dust-proof and shock-proof 3.Large screen high resolution LCD screen, the interface
has Chinese prompts, more intuitive display content 4.Built-in large capacity memory card, storage capacity upgrade 5.USB
transmission simulates the host computer as a U disk and reads data as easily as a U disk 6.Real-time display of protective layer
thickness and steel signal image, minimum automatic locking 7.Dual-range operation mode can effectively ensure the detection
accuracy and maximum detection depth 8.Automatic storage of test data, on-site statistical analysis results are provided
immediately, which is convenient for guiding construction work 9.Professionaldata analysis software, so you’re your post-
processing data and report generation work can be easily completed
2.Adopt three anti-shell design, waterproof, dust-proof and shock-proof 3.Large screen high resolution LCD screen, the interface
has Chinese prompts, more intuitive display content 4.Built-in large capacity memory card, storage capacity upgrade 5.USB
transmission simulates the host computer as a U disk and reads data as easily as a U disk 6.Real-time display of protective layer
thickness and steel signal image, minimum automatic locking 7.Dual-range operation mode can effectively ensure the detection
accuracy and maximum detection depth 8.Automatic storage of test data, on-site statistical analysis results are provided
immediately, which is convenient for guiding construction work 9.Professionaldata analysis software, so you’re your post-
processing data and report generation work can be easily completed
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
