Ultrasonic Test for Concrete Sonic Test for Piles

Ultrasonic Test for Concrete Sonic Test for Piles thumbnail-1
Ultrasonic Test for Concrete Sonic Test for Piles thumbnail-2
Ultrasonic Test for Concrete Sonic Test for Piles thumbnail-3
Ultrasonic Test for Concrete Sonic Test for Piles thumbnail-4
Ultrasonic Test for Concrete Sonic Test for Piles thumbnail-5
Ultrasonic Test for Concrete Sonic Test for Piles photo-1
Ultrasonic Test for Concrete Sonic Test for Piles photo-2
Ultrasonic Test for Concrete Sonic Test for Piles photo-3
Ultrasonic Test for Concrete Sonic Test for Piles photo-4
Ultrasonic Test for Concrete Sonic Test for Piles photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Contact Supplier Request Quote Chat Now
Cangzhou Lovely Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Usage Overview


U950/U960Non-metallic ultrasonic detector(multi-tube measuring pile)Ultrasonic transmission method for pile integrity testing,
Structural concrete compressive strength, crack depth, crack width and defect detection; Diaphragm wall integrity testing, which
integrates five functions of pile testing, ultrasonic rebound comprehensive method for strength measurement, defect detection,
crack sounding and width measurement. Geological exploration, rock integrity, weathering evaluation test; mechanical properties of
non-metallic materials such as rock mass and concrete.
Product Description

· Integral design, compact size


· Easy to carry and make work efficient



·
Specification
Product Model
U950
U960
Master unit
Built-in A8 industrial control motherboard
Built-in A8 industrial control motherboard
Display
10.1 inch, high brightness, TFT color LCD capacitive screen
10.1 inch, high brightness, TFT color LCD capacitive screen
Operational mode
Touch screen
Touch screen
Storge mode
Built-in Electrionic Hard Disk(＞8GB)+ Large Capacity U Disk
Built-in Electrionic Hard Disk(＞8GB)+ Large Capacity U Disk
Acquisition mode
Synchronized continuous rapid mining
Synchronized continuous rapid mining
Number of channels
3 Channels Spontaneous Receiving
4 Channels Spontaneous Receivingannels
One-time section number
3
6
Trigger mode
Signal triggering
Signal triggering
Test method
Plainning Re-testing Encryption. Oblique Survey
Plainning Re-testing Encryption. Oblique Survey
Data transmission mode
Wireless Cloud Transport(Options)
Wireless Cloud Transport(Options)
Acoustic Time Accuracy(μs)
0.05
0.05
Sampling period(mμs)
0.05-409.6 Multistage Options
0.05-409.6 Multistage Options
Acoustic time range(mμs)
±1677700
±1677700
Dynamic range(dB)
146
146
Width measurement function
Measuring range: 0~10mm; Measuring accuracy: 0.01mm
Measuring range: 0~10mm; Measuring accuracy: 0.01mm
Bandwidth(kHZ)
1~500
1~500
Receiving Sensitivity(UV)
Less than 10
Less than 10
Gain Accuracy(dB)
0.5
0.5
Emission Voltage(V)
65, 250, 500 and 1000 gear adjustable
65, 250, 500 and 1000 gear adjustable
Communication interface
USB, Bluetooth, Wifi
USB, Bluetooth, Wifi
Working hours

more than 8

more than 8
Powder supply mode
Built-in lithium battery External 220V~16V AC/DC
Built-in lithium battery External 220V~16V AC/DC
Working environment
-10~40℃ Humidty (RH) ＜90%
-10~40℃ Humidty (RH) ＜90%
Host size(mm)
300x200x55
300x200x55
Our Advantages
Installation and training
· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
· Without visiting, we will send you user manual and video to teach you to install and operate.

After Service
· One year guarantee for whole machine.
· 24 hours technical support by email or calling

Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.

Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.

Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.

Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.

Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.

Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
