Product Description
AT343 TABER Abrasion Tester is used to determine the abrasion resistance of rubber product, plastic film and textile, it is also suitable for leather, carpet and other material.
Standard
ASTM D1044, D3884 | ISO 5470-1 | DIN53863.2 |
Specification
Model | AT343 | ||
Specimen size | φ116mm×φ9mm | ||
Abrasive wheel | Diameter | 2” | |
Thickness | 1/2” | ||
Rotating speed | 30~90rpm adjustable | ||
Distance between abrasive wheel and sample center | 37~38mm | ||
Load | 500g, 750g, 1000g, 1250g | ||
Counter | 0~999,999 | ||
Power supply | AC220V 50Hz or customized | ||
Dimensions | 516mm×300mm×417mm | ||
Weight | 40kg | ||
Details & Features
★ Body is made up of high quality material
★ Testing speed is settable
★ Select high quality components
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
