Desktop Plastic Lab Injection Molding Machine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

AT393B Lab injection molding machine is use to make the thermoplastic or thermosetting plastics into various shapes of plastic products by use of different plastic molding die. Injection molding machine can be heating plastic, and applying a high pressure to the molten plastic, inject the molten plastic to full of the mold cavity.

Specification

Model	AT393B
Feeding torque	25.4N·M
Pressure	0.8Mpa
Injection stroke	0-85mm
Feeding speed	1-130rpm
Mold opening stroke	82mm
Injection force	1800kg
Injection capacity	45g
Maximum temperature	Zone 1/2 360℃; Zone3 180℃
Control accuracy	0.5℃
Screw diameter	25mm
Tiebar distance	210*196mm
Dimension	5885170cm
Net Weight	380kg
Power supply	220V 50HZ 2.2KW

Details & Features

★Adopt color touch screen, simple operation

★The mechanical and electronic double protection device, to ensure safety

★High energy saves

★Quiet operation, molding stability

★This machine has the advantages of small volume, strong mobility, making suitable for classroom teaching and small sample

★Excellent corrosion resistant stainless steel, beautiful appearance

★The products include mold parts, sol injection body, heating system, control system and charging device.

★Simple structure, convenient

operation, no noise and no pollution

★With 220V voltage, can used in any field, from the electricity industry limited.

Our Company

History

Since 1982 with more than 20 years’ experience

Warranty

Two Year Warranty for whole product

Training

Video and user manual for training

Onsite service

Installation and training service is available

Testing service

Free sample testing before order is available

Lead time

15 working days lead time for most product

Packing & Delivery

Packaging
Packaging Details	1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated.

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
