Home > Computer Products > Mainboard > Ac7k04 Intelligent 7KW Single Phase AC Charging Pile Control Panel Ev Charger Main Board Of New Energy Charging Box
Ac7k04 Intelligent 7KW Single Phase AC Charging Pile Control Panel Ev Charger Main Board Of New Energy Charging Box
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1992
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Three Phase 11KW 22KW On Board Charger Ac Controller Board Car Charging Station PCB Circuit Board For Electric VehicleNegotiableMOQ: 1 -
New Energy Car Charging Pile Ac Control Board 3 Phase Electric Car Charger Circuit BoardNegotiableMOQ: 1
-
Single Phase PCB Motherboard Electric Car Special Charging Controller Circuit Board PCBA Ev Charger Control Board SuppliersNegotiableMOQ: 1
-
16A 32A 3.5KW 7KW Portable EV Charging Box Replacement Mainboard EV Ac Charger Controller Main Circuit BoardNegotiableMOQ: 1
-
Household Electricity 220V 16A AC Single Phase EV Charger Module PCB BoardNegotiableMOQ: 1
Product Description
Ac7k04 Intelligent 7KW Single Phase AC Charging Pile Control Panel Ev Charger Main Board Of New Energy Charging Box
AC7K04 Control board
1.This product is the main control board of 7kW single-phase AC charging pile, which is mainly used for AC charging of electric vehicles.
2.The product is composed of charging pile main control board, Ethernet communication board, 4G communication board, BT communication board, card reader board, display screen, external LED indicator light, etc.
3. It has the functions of charging protection, card charging, scanning code charging, mobile payment,network monitoring, etc.
4.This product adopts the principle of industrial design, convenient installation, quick deploymen.
Item Name | 7KW Single Phase AC Charging Pile Control Panel | |
Brand Name | Hansshow | |
Dimensions | 130*100* 30 ( L*W*H )mm | |
Starting mode | Plug and charge/RFID | |
Installation | wall-mountingpedestal | |
Communication mode | BT/Ethernet/4G/RFID | |
Weight | 220g | |
Input frequency | 50/60Hz | |
Input power | 7KW | |
Working voltage | 175-265V | |
Waterproof Level | IP56 | |
Output current | 32A | |
Environmental index | ||
Applicable scene | indoor / outdoor | |
Working temperature | -30℃ ~ +55℃ | |
Working Humidity | 5% ~ 95% no condensation | |
Working altitude | <2000m | |
Cooling Type | natural cooling | |
Standard | EN 61851-1-2001,EN 61851-22-2001 | |
MTBF | 50,000 H | |
Protection Function | ||
Overvolatge protection | 265V | |
Undervolatge protection | 175V | |
Leakage protection | 30mA(Type A),(TypeB opt) | |
Overcurrent protection | ≥110% rated output | |
Overtemperature protection | 80℃ | |
Grounding protection | Yes | |
Lightening protection | Yes | |
