Highly Efficient Gold CIP Plant Leaching Agitation Tank , Minerals Cyanide Leaching Tank for CIL Plant
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Customized 6S Shaking Table For Copper Ore Gold Panning Equipment Small Gravity Separator Shaking Table Mineral Processing
-
High Recovery Rate Gravity Separator Machine Spiral Chute for Beneficiation Plant Price
-
Rotary Trommel Scrubber Washing Machine Scrubbing Machine for Ore and Stone Washing For Sale
-
Ore Sludge Slurry Industrial Cone Thickener With Various Model
-
Flotation Process Agent Mixer Tank
-
High Recovery Gold Mining Equipment Knelson Type Centrifugal Gold Concentrator Falcon Centrifugal
Product Description
Product Description
Product Application of Mining field gold chemicals agitation leaching tank
Gold ore leaching tank features of reasonable and compact structure, high transmission efficiency. Gold ore leaching tank adopts two new type bigger impellers, low rotational speed,less powerconsumption, inside hollow shaft can suck the air into the tank,and improve the leaching environment. Gold ore leaching tank is widely used in gold and silver ore
dressing plant for cyaniding treatment, CIP process, and carbon-in-leach work.
Gold ore leaching tank features of reasonable and compact structure, high transmission efficiency. Gold ore leaching tank adopts two new type bigger impellers, low rotational speed,less powerconsumption, inside hollow shaft can suck the air into the tank,and improve the leaching environment. Gold ore leaching tank is widely used in gold and silver ore
dressing plant for cyaniding treatment, CIP process, and carbon-in-leach work.
Specification
Main feature of Mining field gold chemicals agitation leaching tank
1.Smooth movement, pulp mixing, less power consumption.
2.air after driving hollow shaft into the groove, and the blade agitation, air dispersion evenly.
3, compact structure, convenient maintenance.
4, to the bottom of the hollow shaft ventilation, air through it into the slot, uniform dispersion, small air bubbles.
5, the two new type of impeller, the impeller diameter, low speed, small power consumption, can reduce carbon wear.
6, stirring intensity, moderate groove pulp density, fineness distribution is consistent, can improve the rate of pass in and out of cyanide and charcoal adsorption rate.
1.Smooth movement, pulp mixing, less power consumption.
2.air after driving hollow shaft into the groove, and the blade agitation, air dispersion evenly.
3, compact structure, convenient maintenance.
4, to the bottom of the hollow shaft ventilation, air through it into the slot, uniform dispersion, small air bubbles.
5, the two new type of impeller, the impeller diameter, low speed, small power consumption, can reduce carbon wear.
6, stirring intensity, moderate groove pulp density, fineness distribution is consistent, can improve the rate of pass in and out of cyanide and charcoal adsorption rate.
Technical Parameter
model | tank size (mm) | volume (m3) | impeller dia. (mm) | impeller speed (r/min) | power (kw) | weight (kg) |
SJ-2025 | Φ2000×2500 | 6 | 900 | 52 | 2.2 | 2100 |
SJ-2531 | Φ2500×3150 | 13.14 | 935 | 52 | 2.2 | 3100 |
SJ-3030 | Φ3000×3000 | 18 | 1130 | 41 | 4 | 4150 |
SJ-3035 | Φ3000×3500 | 21 | 1130 | 43 | 4 | 4400 |
SJ-3535 | Φ3500×3500 | 30 | 1310 | 52 | 5.5 | 4900 |
SJ-3540 | Φ3500×4000 | 32.7 | 1310 | 52 | 5.5 | 5200 |
Certifications
Factory view
FAQ
Contact Us
