Customized vertical shaft compound impact stone crusher mobile Impact rock crusher primary impact crusher machine price

Name: Customized vertical shaft compound impact stone crusher mobile Impact rock crusher primary impact crusher machine price
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Customized vertical shaft compound impact stone crusher mobile Impact rock crusher primary impact crusher machine price

Combining outstanding manufacturing process and accurate analytic technique, Liming Machine Made Construction Sand Impact Crusher.

Impact Rotary Rock Crusher takes advantages of safety operation and large carrying capacity, particularly, the semi automatic adjusting device highlights intellectualization and advancement.

It is widely used in metallurgy, mine, cement, chemical engineering, fire resistant mterials, ceramics and other industrial sectors, as well as in the expressway construction, water conservancy project, building crushed stone, and machine-made sand process fields, etc.

What is the specifications of the Liming Machine Made Construction Sand Impact Crusher, Impact Rotary Rock Crusher?

Model	Rotor size (mm)	Feed opening (mm)	Max. Feed size (mm)	Capacity (t/h)	Power (kW)	Weight (t)	Overall dimension (mm)
PFW1315Ⅲ	1300×1500	625×1530	300	180-270	200(270)	20	2960×2570×2380
PFW1318Ⅲ	1300×1800	625×1830	300	220-300	250(350)	23	2960×2870×2380
PFW1415Ⅲ	1400×1500	800×1530	350	280-350	250(350)	22.5	3120x2650x266

Model	Rotor size (mm)	Feed opening (mm)	Max. Feed size (mm)	capacity (t/h)	Power (kW)	Weight (t)	Overall dimension (mm)
PFW1315Ⅱ	1300×1500	1200x1530	600	180-320	200(270)	21.5	2700x2570x2800
PFW1318Ⅱ	1300×1800	1200x1830	700	240-400	250(350)	25.5	2700x2870x2800
PFW1415Ⅱ	1400×1500	1300x1530	700	300-480	250(350)	25	2900x2700x3000

Product Feature

Working principle

The machine is a kind of crushing equipment which can use the impact energy to break the material.when the material ehters the plate hammer function area,high-speed impact plate hammer the broken material constantly ran to the impact device above the rotor plate,then bounced back plate hammer area again from the back lining mterial,from big to small in the crushing cavity repeated broken Until the material is broken to the required size,the lower part of the machine is dischanged.

Application

Widely used in mining,sand and gravel,water conservancy and hydropower,highway.railway,chemical industry,building materials and

other industries in the crushing and plastic the machine has a simple structure,no key connection, unique counter lining, high efficiency and energy saving,the product is cubic, the size of the particile size can be adjusted,the crushing process can be simplified,and the production cost can be saved.

Impact crusher features:
1.Wide feeding inlet, high crushing cavity,.

2.Suitable for materials with high hardness and lumpiness, less stone powder and
suitable for requirement of high-quality materials.
3.Complete crushing function, high productivity, less consumption of machine parts and
high comprehensive efficiency.
4.Keyless connection, convenient maintenance, economical and reliable.

Concrete Limestone Industrial Impact Crusher Machine For Sale

Product &Details

Not find same as you want ? Please Click here !

Company Information & Certification

Hengchang headquarters is located in the industrial park in Gongyi City. It covers a total area of 150,000 square meters,including 100,000 square meters of standarized workshop. There are more than 200 sets of various large and medium-sized metal processing
lathe, riveting machine, welding equipment and assembly equipment. We have more than 300 workers, including more than 20 middle and senior technicians. Hengchang is mainly focus on 4 series products: stone crusher machines, sand making equipment, powder
grinding mills, mineral processing equipment and their spare parts. Every year, Baichy can turn out 1,000 sets of crushers and 10,000 tons of crusher parts..

Exhibition & Customer Visit

Customer Site

Our machine has been sold to Germany, Australia, Japan, Mexico, Philippines, Indonesia, Russia, Uganda, Uzbekistan, Zimbabwe, etc. and our products are well received by customers. Welcome to inquiry!

Our Service

Before-sale services:

We guide customers to choose the best and applicable device; provide the advanced, energy-saving and practical technological processes, as well as we are responsible for the planning and design of the site.
Sale services:
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
After-sale services:
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.
Solemn Promise:
The quality guarantee period of machines is one year except the wearing parts
Tips:
The prices in the web only to be reference,according to raw material's price fluctuations; Specific price is subject to the negotiation.

Packing &Delivery

Packaging Details:

Standard export packing, Spare parts in wooden case, big machines loaded incontainer,large machines use nude packing, cover with plastic cloth. We export through QingdaoPort, also can be nominated by customer. We have superior cargo agent
to arrange thesea shipment for each client, competitive price, secure transportation. Delivery Time:
We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 10 to 20 working days.

FAQ

1.In order to provide you the suitable quotation we need to know the following information:
1).What is the raw material for the production line?
2).What is the capacity per hour you required?
3).What is the maximum input size of the raw material?
4).What is the output size and application for the final product?

Once we get your answers, I can provide you the best quotation immediately.

2.What about Warranty of the products?
Hengchang Machinery grants our customers a Twenty-four-month-period warranty from the date of delivery for machines exported from us.
During the warranty period, in case any defect of material or workmanship occurred with spare parts in normal operation, we will at our discretion replace or repair the defective parts freely.

3.The reason you choose Hengchang Machinery :
1).Professional manufacturer of supplying Dry mortar production line equipment,exterior wall paint, drying machine equipment, high speed dispersing machine, true stone paint filling machine, packaging machine equipment and other mechanical equipment;
2).Experienced and professional R&D team and manufacturing team;
3).Professional sales team consisted of dedicated, dynamic and innovative people with international version;
4).Professional logistics service ensuring safety and timely delivery of products all over the world through ocean, airline, road and railway.

4.What is the difference between your machine and others’?
Every machine is unique and has its pros and cons, as is every mine site. We can help you decide your unique situation and decide which tool is right for your job.

5.If you want to know more about our machine equipment, please send us inquiry or contact us directly.
