Tank Bottom Homogenizer High Shear Emulsifying Mixer
- T/T Credit Card
You May Like
-
Shanghai 2stage High Pressure Homogenizer 1000lph
-
2000lph Homogenizing Machine Homogenizer Price Small Scale Homogenizer
-
200L per Hour Silverson Homogenizer
-
Pump Small Scale Silverson High Shear in Line Industrial Milk Pasteurizer Homogenizer
-
1500w Stainless Steel 304/316 Laboratory High Pressure Silverson Ultrasonic Homogenizer Sonicator
-
Mayonnaise Homogenizer Pomade Meat Emulsification Mixing Vacuum Mixer Emulsion
Product Description
Tank Bottom Homogenizer High Shear Emulsifying Mixer
Field of Application:
- Dairy product: milk, ice cream, yogurt.
- Food industry: sauces, beverage emulsion, liquid spices, oil mixtures.
- Pharmaceutical products: ointment, paint, adhesives and others.
- Cosmetics: lotion, bath liquid, cream paste, toothpaste, etc.
Characteristics:
- Category: batch high shear mixer, emulsifier, disperser, normal pressure high shear homogenizing mixer.
- Working principle: continuously shear, homogenize, disperse, emulsify and transfer liquid products by high speed and strong liquidized turbulence power, which is generated by its stator and rotor.
- Material: all parts, which contact products, are supplied with stainless steel, and the main shaft is made of special stainless steel.
- Processing capacity: depending on liquid viscosity, normally like milk liquid, processing capacity from 0.5 m3/h to 130 m3/h.
- Main advantage of mixers from Youcan: simple structure, small size, light weight, low noise and running reliable.
| Model | Motor Power (Kw) |
Power Supply Voltage | Revolution (RPM) |
Length (mm) |
Processing Capacity (L/H) |
Material |
| WRL-90 | 1.5 | 380V/50HZ, and customized |
2900 |
430 | 5-50 | SS 304, 316L |
|
WRL-100 |
2.2 | 2900 | 650 | 50-100 | ||
| WRL-120A | 3 | 2900 | 750 | 100-200 | ||
| WRL-120 | 4 | 2900 | 750 | 100-300 | ||
| WRL-140A | 5.5 | 2900 | 850 | 200-600 | ||
| WRL-140 | 7.5 | 2900 | 900 | 200-800 | ||
| WRL-160 | 11 | 2900 | 1000 | 300-1000 | ||
| WRL-170 | 15 | 2900 | 1100 | 400-1200 | ||
| WRL-180 | 18.5 | 2900 | 1150 | 500-1500 | ||
| WRL-200 | 22 | 1170 | 1200 | 800-2000 | ||
| WRL-220 | 30 | 1170 | 1350 | 1000-3000 | ||
| WRL-240 | 37 | 1470 | 1400 | 1500-5000 | ||
| WRL-270 | 55 | 1470 | 1650 | 2000-8000 |
Note: For cutomized mixers, please feel free to contact WhatsApp/Cell: +86 138 1711 5848.
|
Our Company Name |
Shanghai Youcan Beverage Machinery Co., Ltd |
|
Our Industrial Experience |
More than twenty years. |
|
Machines We Manufacture & Export |
Sanitary stainless-steel made tanks, homogenizers, jacketed kettles, pasteurizers, tubular UHT sterilizers, CIP systems, bottle blowing machines, etc. |
|
Production Lines We Supply |
Mineral water, pure water, carbonated drink, fruit juice, milk, yogurt, cheese and ice cream, etc. |
|
Our Clients |
Beverage, Brewing, Dairy Farm, Dairy Processing, Food, Personal Care, Pharmaceutical industries, etc. |
|
Our Expertise |
1. With our fully-experienced research and development team, we are capable of solving any technique problems concerning your production and meet all your whole-line and machinery demands.
2. With two-decade experience in beverage machinery, we are confident to supply all machines meeting your unique requirements. |
|
Ports Our Machines Delivered |
Shanghai, Ningbo, Guangzhou, and other China main ports, and all other international destinations. |
