BNVIS-S210 BNVIS-S220 Single Beam Scanning Visible Spectrophotometer

Quantitative measurement: establish standard curve
File management: data preservation, editable fifile name
Performance verifification: verififiable performance specififications
System application: Multilingual operating system
Dismountable lamp room cover, can change lamp easily
Data can be export from the U disk with .CSV and .TXT format
Support general printer with A4 paper printing
The front baffle of the sample room can be dismantled freely
Special leak hole in the sample room
Antirust treatment cell holder
Model | BNVIS-S210 | BNVIS-S220 | |
Optical system | Single beam,1200 l/mm grating | ||
Wavelength range | 315~1100 nm | ||
Spectral bandwidth | 4 nm | 2 nm | |
Wavelength accuracy | ±0.5 nm | ||
Wavelength repeatability | ≤0.2 nm | ||
Wavelength resolution | 0.1 nm | ||
Wavelength swing speed | 6000 nm/s | ||
Wavelength scanning speed | 25~4200 nm/s | ||
Photometric range | -0.3~3 A,0~200 %T,0~9999.9 C | ||
Photometric accuracy | ±0.002A(0~0.5 A),±0.004 A(0.5~1 A), ±0.5 %T(0~100 %T) | ||
Photometric repeatability | ±0.001 A(0~0.5 A),±0.002 A(0.5~1 A), ±0.2 %T(0~100 %T) | ||
Photometric Noise | ≤0.0005 A @ 0 A,500 nm,≤0.001 A @ 1 A,500 nm,≤0.002 A @ 2 A,500 nm | ||
Photometric Stability | ≤0.002A/hr (500nm, 2 hours after preheating) | ||
Stray light | ≤0.05 %T(360 nm) | ||
Baseline | ±0.002A | ||
Function | Photometric, Quantitation, Spectrum, File management, system management, Performance vertification | ||
Light source | Tungsten lamp | ||
Detector | Silicon photodiode | ||
Standard Sample holder | 10 mm 4-cell manual holder | ||
Display | 5 inch TFT color touch screen | ||
Storage | 236 KB (built-in), supports unlimited external expansion (USB memory) | ||
Interface | RS232 serial port × 1 (printer), USB-A × 1 (USB memory/USB printer), USB-B × 1 (computer) | ||
PC software | Optional | ||
Language | 6 Languages, Can Be Switched (English, German. French, Spanish, Portuguese. Simplified Chinese) | ||
Power supply | 100~240 V AC,50/60 Hz,75W | ||
Size | 456(W)×360(D)×185(H) mm | ||
