Gel Size(W×L): 82×88 mm
Gel thickness: 0.75 、1.0、 1.5(mm)
Number. of Gel: 1~2(pieces)
Sample volume: (0.75mm) 11 、15 wells ;
(1.0mm) 11 、15wells
(1.5mm) 11 、15wells
No. of Samples: 11~30
Buffer Volume: ~750(ml)
Dimension(L×W×H): 150×120×115 (mm)
Net weight: 1.5(kg
With a gel casting in original position, no need to move glasses from gel making to elctrophoresis running. It is more
convenient to observe gel preparing through both sides of the glasses.
High transparent polycarbonate material injection molding, impact resistance, high temperature resistance, corrosion
resistance.
Safety cover open button design, convenient opening the cover.
With the background color, easy to be observed in the sample adding and electrophoresis process.
Abundant buffer not only guarantees cooling effects, but also keeps the pH Value stable during the whole experiment process.
Auto-switch-off when the lid is removed.
Parts Name | Description | Quantity |
Body tank with electrode | / | 1 |
Gel Casting base | / | 1 |
Notched glass plates | (W×L):100×100(mm) | 4 |
Spacer plates | With 0.75mm spacer | 2 |
With 1.0mm spacer | 2 | |
With 1.5mm spacer | 2 | |
Comb | 0.75mm thickness,11 wells | 2 |
1.0mm thickness,11 wells | 2 | |
1.5mm thickness,11 wells | 2 | |
0.75mm thickness,15 wells | 2 | |
1.0mm thickness,15 wells | 2 | |
1.5mm thickness,15 wells | 2 | |
Gel shovel | / | 1 |
Wedged-shapde Plates | / | 2 |
Clamp version | / | 2 |
Dummy plate | / | 1 |
Electrical Cables | / | 1 |
