High accuracy concentricity tester WA-10/WA-10G
Features
|
1.Precision measurement for the circularity, concentricity, circular runout of shaft workpiece 2.Precision measurement quickly for outer circle and inner circle of shaft workpiece simultaneously. 3.Precision measurement for muti-points in one shaft workpiece simultaneously. 4.Quick measuring for flush surface, inner circle and outer circle at the same time. 5.Standard accuracy 5um, and high accuracy 3um 6.Quick measuring, no need for re-tooling. 7.Convenient operation, wide range of application. 8.Easy to move, simple to maintain. 9.Demand for operating environment is common. 10.Custom made is available according to particularity of workpieces. 11.It is suitable for measurement of the rotational symmetric workpiece, such as step shaft, shaft sleeve, bushing block etc |
Specification
|
Model number :WA-10 Indicator :Single indicator type Measuring diameter :4-25 mm Measuring length :102 mm Accuracy: 5um Model number :WA-10G Indicator :Single indicator type Measuring diameter :4-25 mm Measuring length :102 mm Accuracy: 3um |
Note
1)All indicator and test gauge needs to order separately.
2)If you have special shaft or parts to test with concentricity gage, pls send us your part drawing, we will recommend the instrument for you. Thanks!
FAQ:
Q:How can we place the order ?
A:Please place order online directly , or you can send us an inquiry , or check with our sales online, we will reply you within 12 hours.
Q:How can we send money ?
A:After you confirm the order , you can send money online directly , we can accept payment by BOLETO, Mastercard, Visa, e-Checking, PAYLATER, T/T etc.
Q:When will you send out our package ? And how long can i receive it ?
A:Usually we can send goods in 1-2 days except China holiday , and it will take 5-6 days to reach your country by DHL , TNT , UPS , FEDEX or e-packet etc.
Q:What is the warranty policy ?
A:Usually we provide 1 year warranty from the date we sent out the package.
Q:How about the product quality ?
A:Our products apply to CE , ROHS , ISO.
Q:If we receive the products without SHAHE logo from your store, are they produced by Wenzhou Sanhe Measuring Instrument Co.,LTD ?
A:Yes, we are SHAHE Factory Direct. We produce tools with SHAHE brand and neutral for meeting different customs’ demand, we will send products with SHAHE logo at first, if no stocks , we may send neutral one , but all are 100% quality products from SHAHE.
Q: Are OEM&ODM available?
A: Yes, we accept OEM and ODM.
