Product Description
Good quality 10/100/1000M 2 port poe splitter
1. Description
- For the cost saving and power management purpose, the PD3101G is the ideal IEEE 802.3af Power over Ethernet device that splits the 48V DC over the Ethernet cable into 5V/12V DC power output.
- When working with the IEEE 802.3af power source equipment (PSE), the PD3101G frees the device deployment from restrictions of power outlet locations, which eliminates the costs for additional AC wiring and reduces the installation time.
2. Product Features
- Complies with IEEE 802.3af Power over Ethernet, IEEE 802.3ab 10/100/1000Base-T Ethernet standard
- Splits the 48V DC power over RJ-45 Ethernet cable into different DC output
- LED indicators for power input indication
- Data and power transmission distance up to 100 meters
- Adjustable two different output voltage options (5V/2A, 12V/1A) to fit various devices
- Auto-Detect of IEEE 802.3af PoE equipment, protects devices from being damaged by incorrect installation
- Works with EIA568, category 5,4-pair cables for 10Base-T or 100Base-TX
3. Order Information
Product:PD3101G
Type:10/100/1000M PoE Splitter,IEEE 802.3af,15.4Watts,5VDC/12VDC output, 10/100/1000M Power Pin Assignment:Data provided over pairs over 1/2and 3/6 ,Power over spare pairs4/5(+) and 7/8 (-)
4. Specifications
2 port poe splitter
| Technical parameter list | |
| Product Name | Gigabit PoE Splitter |
| Model | RB-PD3101G |
| Description | 10/100/1000M PoE Splitter |
| Port Feature | Input: PoE port, Output: DC12/5V , RJ45 |
| Media | 1000Base-TX (≤100, Catalogue 5 cable) |
| Protocol | IEEE 802.3i;IEEE 802.3u;IEEE 802.3x Flow Control;IEEE 802.1af DTE Power via MDI |
| Other Feature | 5V/12VDC Adjustable |
| PoE Port | Power over Ethernet (15.4W) |
| PoE Standard | IEEE802.3af (15.4Watts) |
| PoE Type | Support Both Mid-span and End-Span |
| PoE Feature | Output Power: 15.4 Watts. |
| PoE PIN | 4/5+,7/8- and 1/2+,3/6- |
| Environment | Operating temperature: 0 to 55° C Storage temperature: -20 to 75°C |
| EMI Safety | CE mark,commercial,FCC Part 15 Class B,RoHS |
| PoE Budget | 15.4Watts |
| Leds | Power, Network, PoE working status |
| Dimenssion | 80x76x25mm (0.15Kg) |
| After-Sales | One year’ garantee, Lifetime Maintenance |
| Packing List | PoE Splitter, Certification, User manual, Warranty card |
5. Accessories in the package
2 port poe splitter
| Package Contents | 10/100/1000M PoE Splitter |
| DC power line | |
| Installation guide | |
| Warranty/Support Information card |
