Customized High Precision Sintered Bronze Bushing,oil Impregnated Fan Brass Bushings
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Self Lubricating Washing Machine Oil Impregnated Bronze Bushing
-
CuSn663 Sintered Bronze Self Lubrication Bushing MSP Bush
-
MSP CuSn663 Sintered Bronze Ball Bearing Bush
-
Spherical Ball Bronze Small Electric Motor Bushing and Bearing
-
Supply Bujes Del VentiladorIron Cheap Sintered Iron Sleeve Bush Bearing Fan
-
Cheap Sintered Spherical Bronze Motor Shaft Sleeve Small Electric Motor Bushing and Bearing
Product Description
Product Description
Size | Customized |
Certification | ISO9001, TS16949 |
Material | Bronze powder(Bronze 90% Cu 10% Sn) |
Color | Natural |
Density | 6.4-6.8g/cm3 |
Static load | 200N/mm2 |
Dynamic load | 18N/mm2 |
Max linear speed | 7m/s |
Volume of oil impregnation | 22% |
Hardness | 25HB |
Friction coefficient | 0.03μ |
Traction resistance | 10-20N |
Elongation | 1-2.5% |
Max thermal emperature | -20~120 |
Application | household appliances, electric tools, textiles machinery, chemical machinery and automobiles and official business machines |
Explanation: TCB401 sintered bronze powder bushing is mold pressed under high pressure and then sintered under high temperature, and oil is soaked into the homogeneously spreaded tiny pores of the metal under vacuum. This bearing can withstand dry condition in medium speed and low load for short time. Moreover it is cheap and stable in dimension.
Company Profile
FACTORY WORKSHOP
Tehco is always focusing on the overseas markets, by satisfying the ever-increasing demands of modernization of customers. We could provide products according to the international standards, and could also provide as per the customers' requests. With stable product quality and best level of services, our products have been exported to dozens of countries and regions from the Europe, the United States, and Southeast Asia, etc.
Packing & Delivery
1. Inner Packing
For small products:
100pcs-200pcs per sealed plastic bag.
For bigger products: 2pcs-10pcs per plastic film roller (depends on the product size)
2. Outer Packing
8pcs-300pcs per carton (depends on the product size)
3. Shipment Packing
18-24 cartons per wood case or pallet, shockproof and safe for transportation.
Delivery pictures
Products loaded on container.
Products arrives at the destination.
Customer is unloading.
