Gubot Newest the Laser Scanning System Without Probe System Rim Repair Cnc Wheel Lathe From Factory
Gubot Newest the laser scanning system without probe system rim repair cnc wheel lathe from factory
contact us:Tel & WhatsApp: +8615502118859
Items | Unit | Specifications |
Max.swing over bed | Mm | 560 |
Max. Size of alloy wheel | Inch | 22 |
Cutting feed speed (mm) | mm/min | 0.1-1800 |
Range of spindle speed | rpm | 50-2000 |
Moving speed of X | Mm/min | 12000 |
Distance of X | mm | 300 |
Moving speed of Z | Mm/min | 18000 |
Distance of Z | mm | 400 |
Spindle Length | KW | 3 |
Feed motor | N/m | X:4 Z:6 |
Motor |
| Servo motor |
Wheel positioning accuracy | mm | 0.01 |
Wheel positioning repeatedaccuracy | mm | 0.01 |
Weight | Kg | 1100 |
Size(L*W*H) | mm | 1700*1200*1610 |
1.Components: Use servo motor, it is stabler and low noise than stepper motor. And we use Panasonic high-precision infrared laser detector.
2.The wheel diamond cut machine can repair 10-22 inch wheels.
3.Remote control:If the wheel diamond cut machine has any problems, we can remote control it to solve the problems for you.
4.Remember function and wireless online: 22 inch wheel diamond cut machine LSB200 has remember function,so you only need scan once time for same wheels.
5.Software: Self-developed ”Gubotlathe” control software, and we will update it in 6 month, free update to the latest software.
6.Appearance: Our machine appearance is designed for wheel diamond cut machine, not change from other CNC machine. It has beautiful appearance and reasonable.
7.17 inch LCD touch screen, windows 7 operation system. Easy to operate.
8.Self-lubricating system.
9.Laser scanner: High precious and only two minutes to scan wheels surface.
10.Wheel repair is easy to learn, no need to program, It only need half day to study this machine for a new person.
11.Cost-effective, good quality with competitive price.
We use the wooden pack the machine and it will be very safe to ship.
And the machine will not be damaged during transportation.
COMPANY PROFILE
Founded in January 2006, Gubot is located in Building 6, No. 85, Sanda Road, Minhang District, Shanghai, with a registered capital of 10 million dollars. It is a high-tech enterprise that is technology research and development, business cooperation and intelligent manufacturing focused on the automotive aftermarket. With excellent talents and leading technology, the company is committed to the high integration of technology research and development and innovation, and entrusts its wholly-owned subsidiary: Anhui Gubot Tianji Intelligent Technology Co., Ltd. to produce a series of innovative, practical, energy-saving and environmentally friendly, intelligent products. We provide new supporting products and technologies in the aspects of personalized car beauty, technology micro- repair and re-manufacturing and the Internet, which is the traditional automobile aftermarket. Provide a complete system solution for car detailing shop and car repair shop.
