cranes for sale 600 ton crawler crane other cranes
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
China Brand New 25 ton hydraulic other cranes crane truck for sale STC250
-
mini crane 12 ton truck crane pickup truck crane STC120C
-
160 ton mobile hydraulic foldable truck jib cranes STC1600
-
China Brand New 100 ton crane price for sale STC1000T
-
other cranes mini small 55 ton crawler crane XGC55 for sale
-
Hydraulic Crane 55 Ton Truck Crane ZTC550E552
Product Description
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
We supply all kinds of crawler crane, including 55 ton, 75 ton, 85 ton, 100 ton, 120 ton, 130 ton, 150 ton, 180 ton, 260 ton, 400 ton , 500 ton crawler crane.
Products Description
1. Optimized design of transport and assembly/ disassembly
* Basic machine is an integrated transport design, without disassembling track frame and boom base, greatly save transport costs and improve the assembly/disassembly efficiency.
* Unique A-frame gantry self-erection technology, no need of cylinder can achieve self- erection, to realize crane quick assembly.
* Single counterweight weighing no more than 4t, small auxiliary lifting equipment can achieve complete counterweight assembly.
2. Opimized hydraulic system design
* Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance.
* Use of highly integrated LUDV main valve, with the functions of multi-complex operation, control of combined flow, high/low speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
3. Main/ auxiliary hook one-key-switch-over function
One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
* Basic machine is an integrated transport design, without disassembling track frame and boom base, greatly save transport costs and improve the assembly/disassembly efficiency.
* Unique A-frame gantry self-erection technology, no need of cylinder can achieve self- erection, to realize crane quick assembly.
* Single counterweight weighing no more than 4t, small auxiliary lifting equipment can achieve complete counterweight assembly.
2. Opimized hydraulic system design
* Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance.
* Use of highly integrated LUDV main valve, with the functions of multi-complex operation, control of combined flow, high/low speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
3. Main/ auxiliary hook one-key-switch-over function
One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
Specification
Item | Unit | Parameter | ||
Parameter item | - | XGC75 | ||
Performance parameters | ||||
Main boon rated liad | (t) | 75 | ||
Fixed jib rated lifting weight | (t) | 12 | ||
Max Lifting Moment | (t.m) | 286 | ||
Working condition of single arm end pulley maximum rated lifting weight | (t) | 6.5 | ||
Dimension parameter | ||||
Main boom length | (m) | 13~58 | ||
The main luffing Angle | (°) | -3~80 | ||
Fixed jib length | (m) | 7~19 |
Details Images
