6.5 Ton Small Crawler Excavator LOVOL FR65E2
Alivior Liu
Three-pump Throttling system makes rational match of main pump output power
and operational load, hydraulic efficiency rises 5%.
Rely on LOVOL Japan Technology Center, we sets up strong cooperation with
renowned enterprises for key components.
Dozer blade uses resistant material, box structure design that improves the
reliability.
Track roller adopts axial restraint which increases the stability and improves the
strength of structure.
|
Item |
Unit |
Specifications |
|
Rated Power |
kW/rpm |
36.2/2100 |
|
Bucket Capacity |
m³ |
0.25 |
|
Operating Weight |
kg |
6200 |
|
Engine Model |
4TNV94L |
|
|
Number of Cylinders |
4 |
|
|
Max. Torque/Speed |
N·m/rpm |
198/1400 |
|
Displacement |
L |
3.054 |
|
Main Performance |
||
|
Bucket Digging Force |
kN |
50 |
|
Arm Digging Force |
kN |
31 |
|
Max. Traction Force |
kN |
49.2 |
|
Max. Walking Speed |
km/h |
4.2 |
|
Min. Walking Speed |
km/h |
2.4 |
|
Rotary Speed |
r/min |
11 |
|
Gradeability |
° |
35 |
|
Ground Pressure |
KPa |
31.25 |
|
Hydraulic System |
||
|
Max. Main Pump Flow |
L/min |
158 |
|
Main Safety Valve Pressure |
MPa |
24.5 |
|
Fuel Tank |
L |
120 |
|
Hydraulic Tank |
L |
90 |
|
Engine Oil |
L |
5.5-10.5 |
|
Shipping Length |
mm |
6090 |
|
Shipping Ground Length |
mm |
3760 |
|
Boom Height |
mm |
2300 |
|
Shipping Width |
mm |
1950 |
|
Cab Height |
mm |
2660 |
|
Ground Clearance of Counter weight |
mm |
700 |
|
Min. Ground Clearance |
mm |
330 |
|
Tail Turning Radius |
mm |
1700 |
|
Wheel Tread |
mm |
2145 |
|
Track Length |
mm |
2685 |
|
Track Gauge |
mm |
1540 |
|
Track Shoe Width |
mm |
400 |
|
Hood Height |
mm |
1635 |
|
Rotary Platform Width |
mm |
1830 |
|
Max. Digging Height |
mm |
5405 |
|
Max. Dumping Height |
mm |
3770 |
|
Max. Digging Depth |
mm |
3660 |
|
Max. Vertical Digging Depth |
mm |
2655 |
|
Max. Digging Radius |
mm |
6065 |
|
Max. Ground Digging Radius |
mm |
5925 |
|
Min. Turning Radius |
mm |
2660 |
