496kN 90tons 5.6m3 bucket largest crawler excavator 990F with 2806 IIIN engine

Take a walk around the New 990F and you will see the difference. It’s a big, tough machine that’s high on productivity, reliability and operator safety and comfort.
Punching a massive 496 kN of digging force, the New 990F easily out-performs any competitive machine in its class.
The 990F works hard to deliver the best return for your investment by reducing overheads on fuel through smart engine technology to ensure maximum efficiency, to state-of-the-art engine oil and hydraulic fluid filters increasing performance by thousands of hours.
The New 990F is designed to deliver maximum uptime, shift after shift. With toughness and durability built into the heart of machine, the 990F works harder for longer in the toughest of jobsites.
Tough, dusty conditions give air filters a real workout. The oil bath air pre-filter on the New 990F protects, cleans and extends the filter life to 1,000 HOURS.
Our new pressurized cab keeps dust, noise and contaminants away while the automatic climate control surrounds you with fresh, filtered air for cooling or heating depending on the environment.

Operating weight with cab 93000 kg
Engine power 447.5 kW (600 hp) @ 2100 rpm
Bucket capacity 5.6 m³
Maximum travel speed (High) 4.2 km/h
Maximum travel speed (Low) 2.6 km/h
Maximum swing speed 6.4 rpm
Arm breakout force 392 kN
Arm breakout force Power boost 413 kN
Bucket breakout force 472 kN
Bucket breakout force Power boost 497 kN
Shipping length 13757 mm
Shipping width 4500 mm
Shipping height 5228 mm
Track shoe width (std) 650 mm
Boom 7250 mm
Arm 2925 mm
Digging reach 12488 mm
Digging reach on ground 12172 mm
Digging depth 7185 mm
Vertical wall digging depth 5395 mm
Cutting height 12342 mm
Dumping height 7979 mm
Minimum front swing radius 5415 mm
Model Per-kins 2806 IIIN
Emission Tier 3 / Stage IIIA
System maximum flow 2 × 504 L/min
System pressure 35 / 37.3 MPa
