Product Description
LOVOL brand 22 tons hydraulic excavator FR220D/FR220D2 with ISU-ZU or Cu-mmins EURO II engine price
Product Description
FR220D/FR220D2 difference:
Lovol 22-ton exporting models, FR220D, equipped with Isu-zu engine + Kawa-saki hydraulic system;
The other is FR220D2, equipped with Cum-mins engine + Doo-san hydraulic system
| Major specification | Operating weight | kg | 22200 | |
| Bucket capacity | m3 | 0.96 | ||
| Bucket digging force(standard) | KN | 139 | ||
| Bucket digging force(High power) | KN | 143 | ||
| Stick digging force(standard) | KN | 108 | ||
| Stick digging force(High power) | KN | 116 | ||
| Travel speed(H/L) | km/h | 4.9/2.7 | ||
| Swing speed | rpm | 11 | ||
| Max traction | KN | 217 | ||
| Gradeabiity | 35o | |||
| Ground pressure | Mpa | 44.9 | ||
| Noise(in cab) | Db(A) | 73 | ||
| Noise(out of cab) | Db(A) | 104 | ||
| Power unit | Engine | Emission | Stage II/Tire II/Euro-II | |
| Brand | Cum-mins | |||
| Model | 6BTAA5.9-C150 | |||
| Power | KW/RPM | 112/1950 | ||
| Cylinder | 6 and in line | |||
| Displacement | L | 5.9 | ||
| Bore and stroke | mm | 102x120 | ||
| Max torque | N.M/RPM | 614/1500 | ||
| Hydraulic system | Type | Negative flow control | ||
| Pressure | Work tools(Mpa) | Standard | 34.3 | |
| High | 37.3 | |||
| Swing(Mpa) | Standard | 25.5 | ||
| High | 25.5 | |||
| Travel(Mpa) | Standard | 34.3 | ||
| High | 34.3 | |||
| Pump | Brand | Doo-san | ||
| Model | DPA117T-0N8D-2N1L | |||
| Rated speed | rpm | 2450 | ||
| Rated pressure | Mpa | 34.3 | ||
| Valve | Brand | Doo-san | ||
| Model | MV270 | |||
| Pressure(standard model) | Mpa | 34.3 | ||
| Pressure(High model) | Mpa | 36.3 | ||
| Swing motor | Brand | Doo-san | ||
| Model | TMS140-RG1600 | |||
| Displacement | CC/R | 120 | ||
| Max pressure | Mpa | 26.5 | ||
| Max flow | L/min | 206 | ||
| Max speed allowed | r/min | 1720 | ||
| Max torque | KN.M | 10.899 | ||
| Travel motor | Brand | Doo-san | ||
| Model | TM40VD-A-157/97-1 | |||
| Max pressure | Mpa | 34.3 | ||
| Displacement | cc/r | 157/97.4 | ||
| Max torque | N.M | 42.865 | ||
| Max flow | L/min | 224 | ||
| Max speed allowed | r/min | 2800 | ||
| Cylinder bore and stroke | Boom cylinder | mm | 120*1335 | |
| Stick cylinder | mm | 135*1490 | ||
| Bucket cylinder | mm | 115*1120 | ||
| Working ranges | Max digging depth | mm | 6510 | |
| Max digging reach at ground level | mm | 9690 | ||
| Max digging height | mm | 10190 | ||
| Max loading height | mm | 7260 | ||
| Max vertical digging depth | mm | 5980 | ||
| Dimensions | Transportation Dimensions(L*W*H) | mm | 9580*2980*3060 | |
| Tail swing radius | mm | 2880 | ||
| Track length | mm | 4385 | ||
| Ground clerance | mm | 443 | ||
| Counterweight clerance | mm | 1090 | ||
| Service refill capacities | Fuel tank capacity | L | 385 | |
| Cooling system | L | 34 | ||
| Engine oil | L | 20 | ||
| Swing motor | L | 4 | ||
| Travel motor(each) | L | 4.4 | ||
| Hydraulic oil tank | L | 220 | ||
