Home > Products > Earthmoving Machinery > New 6 Ton Wheel Loader LW600FV With EURO III Engine WP10G240E341

New 6 Ton Wheel Loader LW600FV With EURO III Engine WP10G240E341

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

New 6 ton Wheel Loader LW600FV with EURO III engine WP10G240E341

LW600FV wheel loaders is equipped with dedicated Weichai engine, electronic control transmission, and patented automatic power distribution (APD) hydraulic system. The steering plunger pump can, based on different working conditions and statuses of the loader, supplies the oil of different pressures and flows to the working system and steering system to automatically optimize the shares of engine power for drive system and hydraulic system, reduce the fuel consumption, and remarkably improve the working efficiency of machine.

Performance Highlights:
The ≥17.4t traction force and ≥20.5t breakout force conquer all kinds of severe working conditions.
The 38° steering angle and the 3,350mm wheelbase adapt to diversified narrow working sites.

Model Characteristics:
1. Electronic control transmission
heavy-duty electronic control countershaft transmission is in line with the international level in terms of reliability,
operation comfort, multi-functionality, and technologic advancement and has gained multiple national patents.

2. Lightweight design technology
exclusive high strength skeleton frame system is applied and the dynamics simulation research, the in-depth finite element analysis, and the lightweight design are taken to realize that the “load-carrying material ratio” is remarkably leading the industry products.

3. Patented bushing lubrication technology
The industry’s pioneering bushing lubrication structure is applied to prolong the life of the hinge pins by more than one time.

4. Patented double-limit technology
The combination mode of primary flexible limit and secondary rigid limit attenuates the impact onto the frame and improves the
operation comfort.

Specification

Description	Unit	Specification
Dumping height (Ground to main cutting blade)	mm	3170-3750
Dumping range (Front wheels to main cutting blade)	mm	1200-1360
Wheel tread	mm	2265
Hinge height at maximum lifting height	mm	4190
Minimum turning radius (tire center)	mm	6005
Overall machine dimensions (L×W×H)	mm	850532003515
Rated load	kg	6000
Bucket capacity	m3	3.0-4.5
Operating mass	kg	20000
Working height	mm	5550
Maximum breakout force	kN	205
Maximum traction force	kN	174
Lifting time of boom	s	≤5.9
Total cycle time	s	≤10.9
Gradeability	°	28
Tire specification		23.5-25
Engine model		WP10G240E341
Emission standard		China-III
Rated power/speed	kW/rpm	178/2200
Oil tank capacity	L	300
Hydraulic oil tank capacity	L	187
