Home > Auto, Motorcycle Parts & Accessories > Auto Engine > Gasoline Engine > T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat

T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat

T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat photo-1
T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat photo-2
T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat photo-3
T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat photo-4
T04B49 Turbo Charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 Turbocharger for Ford Fiat photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2011
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Eastern turbocharger T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat Tractor 8062.25.670 diesel engine kits

  Product Description

Professional Manufacture, Strict Quality Control test, High Quality Turbo Parts.

 Eastern turbocharger T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat Tractor 8062.25.670 engine





sku a709006
gw 16kg
Part Number 465640-5013S
Previous Version 465640-0013, 465640-0012
OE number 4718129, 4810230, 4762527
Description Tractor, Trucks
CHRA 408105-0281 (408105-0083, 408105-5281S)
Turbo Model T04B49
Model 110.17, 115.17, 135.17
Engine 8060.25.600
Displacement 5.8L, 5861 ccm, 6 Cylinders
KW 176
RPM Max 2700
Angle α (compressor housing 349º
Angle β (turbine housing) 325º
Bearing Housing 430027-0025 (186879, 186881)(1100030450)
Turbine Wheel 446905-0001 (451309-0002)(AR57715, 310094A, 317640, 407276-0005, 410188-0014, 410188-0005, 314655)(Ind. 58.35 mm, Exd. 74.2 mm, Trm 46, 11 Blades)(1100040435)
Comp. Wheel 409179-0028 (Dia. 70.00 mm, Ind. 43.70 m, Exd. 5.10 mm, Trm 39, 8 Blades)
Back plate 408045-0034 (408206-0002, 408045-0051, 408045-0006, 4N6863, 104244-0000, 310010, 311708, 197340, AR101787)(1100040360)
Heat Shield 409299-0000 (409299-0001)(311943, 7N0012, 3524773B)
Repair Kit 468100-0000 (188401-0000, 310063, 3524796, 2W0716, 6N7236)(1100040750)
Turbine Housing 432752-0052
Compressor Cover 408173-0518
Turbine Housing AR 1.00
Gasket (turbine inlet) 409039-0000 (Inox Steel)(409039-0001, 210019, 2405022)(1900000006)
Gasket (turbine outlet) 210315 (Stainless Steel)
Gasket (oil outlet) 311496 (210021, 3519807, 413671-0000, 409037-0000)(1900000027)
Gasket (oil inlet) 147837 (210023, 55739, 3755739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 210023-0000)(1900000037)

 Applications

for 1983- Iveco Agricultural Tractor with 8060.25.600 Engine

for 1983- Iveco Trucks 110.17, 110.07, 115.17, 120.17, 135.17, 145.17, 160.17, 175.17 with 8060.25.600 Engine

fit for Ford- Tractor 8430, 8640 with 8060.25.600 Engine

Specifications:

 T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatT04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat



Why choose us:

1. We are the major OE supporting professional manufacturers, the qualified supplier of KAMAZ  BOSCH  CUMMINS etc.

so what: The same purchase price gives you a higher quality product. Reduce your costs and increase your customer satisfaction.



2.We are an integrated casting and assembly factory. Have turbine wheel precision casting workshop and turbine housing casting factory.

so what: Reduce your waiting time and purchase costs.



3. We use the world's advanced testing equipment for in-factory  inspection, producing inspection, dynamic balance test, and out-factory testing.

so what: Reduce after-sales quality issues and increase customer satisfaction.



4. Independent technology R&D department.

so what: You can have the  latest products early than counterparts.

You can customize production according to the needs.



5.Already have a good supplier, why choose us as alternate supplier :compare the price, compare the delivery time, compare the quality, compare the after-sales service, emergency supply.

More product show

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat



Our Company                                                                   T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

Workshop & Equipment

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat



Process and Layout

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

 Testing Equipment

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford FiatOur brand product catalog

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

Our Service

1.OEM Manufacturing welcome: Product, Package...

2. Sample test first.

3. Your inquiry will be replied in 24 hours.
4.We Have Long Term Cooperative Forwarder, which We can Get Special Discount from Express and Sea Delivery.

5. After sending, we will track the products for you once every 3 days, until you get the products. When you got the goods, test them, and give me a feedback. If you have any questions about the problem, contact with us, we will offer the solve way for you.

  Packing

Safe package to  protect the parts .

 1. Plastic bag to protect the item from rust
 2. Foam inside of the carton to fasten the item
 3. Cartoon box packing .
 4. Pallet packing if necessary

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

Warehouse Show

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

  Shipping & Delivery

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat



Certificates

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

Exhibition Show

T04B49 Turbo charger 4762527 79076287 4812547 4718129 4810230 465640-0002 465640-0026 465640-0006 turbocharger for Ford Fiat

FAQ:

Q1. Where is your company?
A: We are located in Fengcheng City Erlongshan Industrial Park, Liaoning Province, China(Mainland)



Q2. What is your terms of packing?
A: Generally, we pack our goods in plastic bags  and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.



Q3. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We’ll show you the photos of the products and packages before you pay the balance.



Q4. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.



Q5. How about your delivery time?
A: Generally, it will take 7 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.



Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.



Q7. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.



Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.



Q9: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers’ benefit ;
   2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
