Customized ISO16028 With 90 Degree Elbow Flat Face JIC Male Threaded Hydraulic Quick Release Coupling 1/2 Inch
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Heavy Duty 2020 VVS High Pressure Screw Type 80Mpa Hydraulic Quick Coupler
-
3/8 Inch Leakless Flat Face Series Hydraulic Quick Coupling Huge Cooling System Communication Base Station
-
ISO7241-1 Part A 3/8 Inch Hose Fittings ANV Series Male and Female Parts Hydraulic Quick Connector for Excavator
-
TOP Quality HPA High Pressure Screw Type Quick Couplings for Machines High Pressure Coupling
-
High Pressure Steel 2-Wire Braided API Certification /Spiraled Hydraulic Rubber Hose
-
Flat Face Type Hydraulic Quick Couplings 1/4 Inch Bsp Hydraulic Hose Tools With Threaded Push in Release Connector
Product Description
Product Description
FF90 series flat face type hydraulic quick connect couplings meet ISO16028 international standard, 90 degree connection angle prevents damage to hydraulic lines, This series is a direct replacement for the standard sized coupler mounted on many models of skid steers and attachments.
Our coupler sizes fit many models of: Bobcat, John Deere, CAT, Kubota, New Holland, CASE, JCB, Thomas, Gehl, Volvo, and ASV skid steers. Flat Face couplers are designed for applications where hydraulic spillage is a concern.
Specifications
Main technical datas | ||||||||
Working pressure | 5076 PSI | |||||||
Rated flow | 12 GPM | |||||||
Seals | Buna-N Seals with Teflon backup ring can operate up to 250° F | |||||||
Female Face Diameter | 1.50 inch (38mm) | |||||||
Male Face Diameter | 0.94 inch (24.5mm) | |||||||
Female Length | 3.39 inch (86mm) | |||||||
Male Length | 3.7 inch (94mm) | |||||||
Hex | 1.42 inch (36mm) | |||||||
Benefits
1. 90 Degree connection angle prevents damage to hydraulic lines
2. Design allows for easy low profile mounting without the need for additional fittings
3. Ideal for adding Grapple on Skid Steer or on boom arm of an excavator
4. Flush face valve design minimizes fluid loss and air inclusion
5. Locking sleeve to prevent accidental disconnection
6. Zinc-nickel plating provides superior corrosion resistance
7. Hardened steel construction with hardened sleeves
8. Allows for minimal pressure drops
9. Easy single-handed push-connect design
10. Nipple seal resists blow-outs
11. Interchangeable with other ISO 16028 standard couplings
Interchangeable With | ||||
Manufacturer | Male | Female | ||
SUMMIT | FF12M-12J-90 | FF12F-12J-90 | ||
Faster | FFH08-61/34SAE M | FFH08-61/34SAE F | ||
Holmbury | H12-M-12JM90 | H12-F-12JM90 | ||
Drawings
Why Choose Us
Related Products
Company Profile
Factory
Workshop
Manufacturing equipment
Warehouse
Office
Jindong Hydraulic is National High-Tech Enterprise and the fixed enterprise of hydraulic basic parts of National Electrical and Mechanical Department, our company established in 2004. we are professional manufacturer and exporter that is concerned with the design, development and production of hydraulic parts. Specially for hydraulic and pneumatic quick couplings and hydraulic valves, hydraulic hose and fitting adaptor. We are located in private industrial park of Jianhu County, Jiangsu Province, China, with convenient transportation access.
We have our own design and R&D team for 16 years. We can tailor products to the requirement of our customers worldwide. We have a full range of perfect from raw materials to the finished product quality testing system. Our products fit the standard of ISO7241-1A, ISO7241-1B, ISO5675, ISO16028. Also, our products can interchange with brand PARKER, FASTER, HANSEN, TEMA, CEJN, NITTO, HOLMBURY, STAUBLI. We have passed ISO9001-2016 certification. All of our products have the CE and TUV certificates.
Our company regard ‘Customer satisfaction, our pursuit’ as our tenet. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
