Home > Products > Mitsubishi > Mitsubishi New Series of CC-Link Factory Control Module CL1XY2-DT1D5S

Mitsubishi New Series of CC-Link Factory Control Module CL1XY2-DT1D5S

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Mitsubishi new series of CC-Link factory control Module CL1XY2-DT1D5S

Model Number		AJ65SBTB32-8DT	AJ65SBTB32-8DT2	AJ65SBTB1-16DT	AJ65SBTB1-16DT1	AJ65SBTB1-16DT2	AJ65SBTB1-16DT3
I/O Type		DC input/trans output / +COM type/sink type
Stocked Item		-	-	S	-	-	-
Certification		UL • cUL • CE
Number of I/O Points
Input/Load Voltage		24VDC / 24VDC
Max. Load Current	1 Point	0.5A
	1 Common	1.2A		2.4A
Connection Wire Type on Input/ Output Sides		Three wire type / Two wire type	Two wire type / Two wire type		One wire type / One wire type		Two wire type / Two wire type
Common Connection		8 points 1 common		16 points 1 common
Internal Current Consumption		45mA		50mA	55mA	50mA	55mA
Dimensions (W x H x D) mm		118 x 50 x 40		118 x 50 x 40
Model Number		AJ65SBTB32-16DT2	AJ65SBTB32-16DR	AJ65SBTB32-16KDT2	AJ65SBTB32-16KDT8	AJ65SBTB32-16KDR	AJ65SBTB1-32DT
I/O Type		DC input/trans output / +COM type/sink type
Stocked Item		-	-	-	-	-	S
Certification		UL • cUL • CE
Number of I/O Points							16 / 16
Input/Load Voltage		24VDC / 24VDC		24VDC / 24VDC	12VDC / 12VDC	24VDC / 24VDC	24VDC / 24VDC
Max. Load Current	1 Point	0.5A				2A	0.5A
	1 Common	1.2A		2.4A		4A / common	3.6A
Connection Wire Type on Input/ Output Sides		Three wire type / Two wire type				Two wire type / Two wire type	One wire type / One wire type
Common Connection		8 points 1 common		16 points 1 common		8 points 1 common
Internal Current Consumption		50mA	85mA	55mA	55mA	100mA	60mA
Dimensions		179 x 50 x 40
(W x H x D) mm
