plc Mitsubishi FX3U-4AD-PTW-ADP 4-channel platinum resistance temperature analog special adapter
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
plc Mitsubishi FX3U-4LC channel temperature module elevator
-
Brand new Mitsubishi transistor output/input plc module For automobile
-
plc Mitsubishi FX2N-8AD Analog Input Blocks for industrial automation
-
Brand new Mitsubishi Transistor output input plc module FX3UC-16MTDSS
-
New and original Mitsubishi Transistor input/output plc FX3UC-32MT/DSS
-
New and Original plc controller Mitsubishi plc In stock FX series FX3UC-64MT/DSS
Product Description
Product Description
Mitsubishi ElectricMelsec iQ-F Series
iQ Platform-compatible PLC Temperature Input Special Adapters
These analog temperature input special adapters are available for FX3 series main units and are used for Pt100 temperature sensor input. The FX 3U -4AD-PTW-ADP special adapters provide users with 4 channels of Pt100 analog input ranging from -100 to 600°C, while the FX 3U -4AD-PT-ADP has a input range of -50 to 250.
Note: These special adapters can only be used with FX3 series main units. When connecting to an FX 3S ,
FX 3G , or FX 3U main unit, an interface adapter or interface board is required.product Instructions
Specifications | FX3U-4AD-PTW-ADP | ||
Power supply | 5 V DC / 15 mA (from main unit); 24 V DC / 50 mA | ||
Analog inputs | 4 (Pt100 sensors) | — | |
Compensated temperature range | -100 to +600℃ | ||
Digital outputs | -1000 to +6000 | 0.63 mV (14 bit +sign) | |
Resolution | 0.2 to 0.3°C | ||
Overall accuracy for fullscale | ±0.5% – ±1.0%* | ||
Related I/O points | 0 | ||
Weight | 0.1 | ||
Dimensions (W x H x D) | 17.6 x 90 x 89.5 | ||
Packing & Delivery
Packing Details : 1pcs/carton
Delivery Details : 1-2 days after order confrimed
Delivery Details : 1-2 days after order confrimed
