DPH-220 High Speed Aluminum Plastic Blister Packing Machine
Application:
DPH-220 blister packing machine is a machine adopts in the lead position of quality, good capability, all-round function, good reliability and high productivity. It adopts auto-controlling technology and uses new material, new craft, and new technology to make the structure more reasonable.
DPH-220 combines the advantages of good forming of flat pattern packing machine and high speed of roller pattern machine. The forming could be done in low speed through reasonable speed matching. And the sealing station, compressing station and punching station could achieve a speed of 120 cutting per minute. High speed is with perfect function
This series machine is at high precise and the latest roller and plate type blister packing machine, developed by our company. It applies to pharmaceutical industry, food industry, medical appliance and electronically area. It is suitable for packing capsules, tablets, milk pieces, candy, electronically element and similar material, with sealing packing in aluminum PVC, paper PVC Blister Package.
Main Technical Data:
Model: ZH-220 | |
Item |
Data |
Capacity |
100-220boxes/min |
Blister Size(L*W*H) |
(65-190)*(30-115)*(4-12)mm |
Carton Size(L*W*H) |
(70-200)*(35-120)*(20-70)mm |
Leaflet Size(L*W) |
(100-250)*(100-170)mm |
Air Consumption |
≥0.2m3/min |
Compressed air |
0.5-0.7Mpa |
Power |
7.5KW |
Machine Size |
4950X1600X1700mm |
Weight |
3500Kg |
Feature:
1.Plate-type universal feeder although easy and not high effective, it is very extensively applied and suitable for large size and small size capsule, various tablets and pills.
2.High speed vibrating feeding. The feeder can suitable for any speed of the machine. Our Vibration Feeder adopts Stainless Steel tube for feeding, Suitable for GMP Standard.
3.High-precise servo stepping. The machine adopts Servo Motor for Running. So the speed adjusting and running will be more accuracy.
4.The machine is equipped Double Sealing makes the Sealing Perfect, no air run trough the seal.
5.Whole Body Stainless steel with Flexi Glasses. Better Appearance.
ZH-100 Multifunction automatic horizontal Cartoning Machine
Application:
This machine is suitable for packing AL/PL Blister, bottle, Pillow Type Bags and other related similar content compact automatic leaflet folding, box opening and loading, batch number embossing as well as sealing technology processes. (Options hot-glue device extra)
The machine adopts PLC Control. Optical detect every part of the machine. The machine will stop automatically and trouble display when machine running exceptional in order to solving trouble in time. This machine can be used separately and also connect with Blister Packaging Machine online.
Main Technical Data:
Steady production speed |
50-100 cartons/min |
Feature:
1. Rejection automatically if no product, nonstandard height or lack of leaflet.
2. Stop automatically if incorrect position of products into carton.
3. Stop automatically if no cartons or out of leaflet continues.
4. Easy to change to different products.
5. Protecting automatically for overloading.
6. Automatically display device for speed and finished products counting.
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
