Product Description
NP-2032 is a fully automatic nucleic acid extraction instrument
launched by Ningbo Scientz based on the needs of clinical large
scale genetic analysis. This machine uses magnetic bead separation
technology, according to the selection of the appropriate kit to separate
and purify nucleic acids in multi-source samples (such as blood,
animal and plant tissues, cells). The entire instrument has stable
performance and low noise, and the operation is automated, fast and
simple. It can simultaneously purify 32 samples. A powerful "assistant"
in clinical genetic testing and molecular biology laboratory research
launched by Ningbo Scientz based on the needs of clinical large
scale genetic analysis. This machine uses magnetic bead separation
technology, according to the selection of the appropriate kit to separate
and purify nucleic acids in multi-source samples (such as blood,
animal and plant tissues, cells). The entire instrument has stable
performance and low noise, and the operation is automated, fast and
simple. It can simultaneously purify 32 samples. A powerful "assistant"
in clinical genetic testing and molecular biology laboratory research
WORKING PRINCIPLE
Use the magnetic rod on the magnetic rod holder in the machine to move the magnetic beads with adsorbed nucleic acids to different
reagent tanks, and then use the magnetic rod sleeve placed on the outer layer of the magnetic rod to repeatedly move the liquid up and down to mix it evenly. Lysis, nucleic acid adsorption, washing and elution, to obtain the purest nucleic acid.
reagent tanks, and then use the magnetic rod sleeve placed on the outer layer of the magnetic rod to repeatedly move the liquid up and down to mix it evenly. Lysis, nucleic acid adsorption, washing and elution, to obtain the purest nucleic acid.
FEATURES
Fast and efficient
Purified nucleic acid purity can meet the needs of various downstream experiments
Nucleic acid recovery rate> 95%, magnetic bead recovery rate> 95%
Total extraction of 32 samples can be completed in about 20-40min (depending on reagents)
Safe and reliable
Fully automatic operation with disposable consumables to reduce personnel contact
Built-in regular UV disinfection, efficient cleaning
Exhaust fan to effectively avoid aerosol pollution
Prevent door opening alarm and automatically stop the movement structure during operation to ensure safe operation
Strong versatility
Multi-speed and multi-module for selection, and can store 100 programs to meet different customer requirements
Custom lysis and elution temperature
Suitable for different samples, such as animal and plant tissues, serum, plasma, etc.
Purified nucleic acid purity can meet the needs of various downstream experiments
Nucleic acid recovery rate> 95%, magnetic bead recovery rate> 95%
Total extraction of 32 samples can be completed in about 20-40min (depending on reagents)
Safe and reliable
Fully automatic operation with disposable consumables to reduce personnel contact
Built-in regular UV disinfection, efficient cleaning
Exhaust fan to effectively avoid aerosol pollution
Prevent door opening alarm and automatically stop the movement structure during operation to ensure safe operation
Strong versatility
Multi-speed and multi-module for selection, and can store 100 programs to meet different customer requirements
Custom lysis and elution temperature
Suitable for different samples, such as animal and plant tissues, serum, plasma, etc.
Specification
Model | NP-2032 |
Sample throughput | 1-32 |
Processing volume | 30-1000ul |
Magnetic bead recovery rate | ＞95% |
Number of magnets | 32 |
Purification sensiticity | Positive detection rate of 100 copies sample＞95% |
Purify the difference between potes | CV＜3% |
consumables | 96deep well plate+magnetic rod sleeve |
cracking temperature | Room temperature to 120℃ |
Elution temperature | Room temperature to 120℃ |
Concussion mixing | / |
Operation interface | 7-inch touch screen,8 shortcut program files |
Internal Program Preset | 8 programs, can store 100 programs |
Program management | New,edit, delete, save as, etc. |
Instrument Expansion Interfance Standard | USB |
Lighting System | YES |
Disinfection | UV disinfection |
Exhaust method | Fan |
Date storage can be stored | Built-in SD card |
Size | 422*422*470mm |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q1.Are you factory or trading company?
We are a factory
Q2.What is your principle for the samples?
We do not provide free sample.
Q3.Which payment can be acceptable?
We could accept the payment by T/T、Paypal etc
Q4.How about your delivery me?
Generally, it will take 7to 15 working days after receiving your payment.Depend on the quantity.
Q5.Service
We could provide Online instruction;Real-time support by call or voice-chat
During warranty time,we can send product accessories when you need for free.
Technical guidance is free and ready forever
Q6.Training
Your technicians can come to our factory for training,SCIENTZ engineers can go your place for local support(insta
llation、training、debugging、maintenance);
Products can be customized according to your requirements;OEM service available with customers' brand
