Shaped Energy Constant Temperature Ultrasonic Extraction Instrument
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1998
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ultrasonic Probe Homogenizer Cell Disruptor MixerNegotiableMOQ: 1 -
Efficient Ultrasonic Mixer for Small SampleNegotiableMOQ: 1
-
CSCB-2GL Ultrasonic Graphene Processing DeviceNegotiableMOQ: 1
-
5L-100L Hot Sale Ultrasonic Extraction Machine for Essential OilNegotiableMOQ: 1
-
High Power Industrial Ultrasonic Nano Superfine Crusher HomogenizerNegotiableMOQ: 1
Product Description
Features
-- High efficiency: ultrasonic technology, magnetic stirring system and constant temperature control system make the reaction more sufficient
-- Intelligent storage: it can set data, store data and control working status
-- Intellectualization: according to the reaction environment, the best ultrasonic effect can be achieved automatically through automatic frequency tracking
-- Flexible parameters: ultrasonic power, time and reaction temperature are adjustable
-- Optional mode: high power ultrasonic and constant temperature system can be used in combination or separately
-- High safety: it has the function of fault self diagnosis and alarm prompt
-- Simple operation: the special multi port reaction bottle can be filled with various gases to participate in the reaction, and can also be fed continuously
Specification
Model |
SCIENTZ-1000C |
SCIENTZ-500C |
SCIENTZ-250C |
||
Ultrasonic power MAX |
1800 W |
900W |
650W |
||
Reaction flask volume |
1000 ml |
500ml |
250ml |
||
Probe diameter |
Ф20 mm |
Ф10mm |
Ф6mm |
||
Power adjustable range |
30%-100% |
15%-100% |
5%-100% |
||
Ultrasonic frequency |
20KHz±1KHz |
22±1KHz |
22±1KHz |
||
Total ultrasound time |
1-999 min can be set |
||||
Ultrasound time |
1-99 S can be set |
||||
Gap time |
1-99 S can be set |
||||
Blender |
1%-30% (maximum speed is 1000 r/min) |
||||
Compressor power |
500 W |
||||
Heating power |
2000 W |
||||
Temperature control method |
PID automatic temperature control |
||||
Temperature measurement method |
dual-channel temperature measurement to monitor the real-time temperature in the reaction system and constant temperature working tank |
||||
Temperature control range |
0-99 ℃ |
||||
Temperature control fluctuation |
≦±1 ℃ |
||||
Constant temperature volume |
6 L |
||||
Abnormal alarm function |
Yes, the device has fault self-diagnosis and alarm prompt function |
||||
Operation record mode |
the device has a working curve screen, which records the temperature change and other parameter changes during operation |
||||
Device control mode |
7-inch TFT touch screen display and integrated control of single chip microcomputer |
||||
Device operation mode |
direct operation on the touch screen, setting parameters such as temperature, power, time |
||||
USB communication port
|
The device comes with a USB communication port, plug in a USB flash drive, and the curve and other information can be saved to the USB flash drive in the form of a picture |
||||
Remote communication serial port |
this function is an optional item, users who need it can purchase it (including the host computer software) and connect it to the computer |
||||
Reaction flask |
The conventional one is a three-necked flask, users who need it can buy a five-necked flask |
||||
