High Speed Food Wet Granulator Mixer Machine Extruder With Online Support
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Easy Operation High Shear Wet Type Granulator Machine Pharmaceutical
-
Nice Price Reliable Quality Wet Type Mixing Granulation Machine
-
Low Maintenance Cost High Shear Mixer Granulator Machine for Food
-
80 kg / Batch High Efficiency Fertilizer Wet Mixing Granulator Machine
-
Wide Range of Application Medical Wet Mixing Granulator for Sale
-
Excellent Performance Rapid Wet Mixer Granulator With Good Price
Product Description
Recommend Products
Products Description
The machine is the new type pharmaceutical machinery, designed on the basis of adopting the principle of one-step granulator. It can blend and mix the dry powder rapidly, then the even wet powder and granulator. It meets the requirements of GMP Standard.
It can be widely used in pharmaceutical industry, chemical industry, foodstuff industry, powder metallurgy, cosmetic industry, dying stuff industry, and so on.
The advantages: high-efficient; fast; even; mixing and granulating in the same chamber.
Model | SED-15SZ-H | SED-50SZ-H | SED-80SZ-H | SED-100SZ-H | SED-130SZ-H | SED-200SZ-H | SED-300SZ-H | ||||||
Volume (L) | 50 | 150 | 200 | 250 | 300 | 400 | 600 | ||||||
Capacity (kg/batch) | 15 | 50 | 80 | 100 | 130 | 200 | 300 | ||||||
Blending speed (rpm) | 300/210 | 270/180 | 270/180 | 188/130 | 160/110 | 120/85 | 120/80 | ||||||
Blending power (kw) | 4/5.5 | 9/11 | 11/14 | 11/14 | 11/14 | 15/17 | 22/30 | ||||||
Cutting power (kw) | 1.5/2.2 | 2.4/3 | 3.3/4 | 3.3/4 | 4.5/5.5 | 6.5/8 | 9/11 | ||||||
Cutting speed (rpm) | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | ||||||
Working time (min) | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | ||||||
Particle size (mesh) | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | ||||||
Overall Size (mm) | 1350*650*750 | 1750*800*1000 | 2050*940*1100 | 2260*940*1100 | 2310*1000*1200 | 2410*1100*1300 | 2610*1230*1500 | ||||||
Weight (kg) | 550 | 698 | 847 | 1020 | 1230 | 1450 | 1800 | ||||||
Feature
1. Mix evenly: making sure the coloring particles or pigment are evenly distributed;
2. Strong blending ability: wetting the material quickly with 8-12% thickness starch slurry;
3. Judging the granulating situation by the max electricity consumption;
4. The production granules are relaxed and snow-like with no block, more particle and little powder;
5. The three procedures of the mixing, wetting and granulating run continuously in one barrel avoiding the pollution of the manual contact;
6. It can produce repeated with the right parameters, such as the time and speed of the mixing and granulating, the consumption of the adhesive, the consumption of the electricity, etc.;
7. The producing time is approx. ten minutes with high efficiency and the production particles can be well compressed;
8. The great applicability: it can be used for pipelining with one-step fluidized granulator, as well as the fluidized drier;
9. Saving the adhesive about 20-25% and shorten the drying time;
10. Features: advanced design, reasonable layout, reliable seal, convenient operation, security, reliable, etc
Details Images
