DC Motor Control Unit System Curtis1266A Controller Assemblage for Shuttle Bus
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Curtis 1266A Intelligent Programmable DC Motor Controller Assemblage for Golf Trolly
-
Curtis Programmable DC Motor Controller Conversion Kit 1268-5403
-
Curtis Club Cart Conversion Kits 1268-5403 Controller With Main Contactor, Heat Sinking Compound, Foot Pedal Etc
-
Curtis Club Car/shuttle Bus DC Conversion Kit 1268-5403
-
Curtis Model 1268-5403 DC Controllers Conversion Kits, 48V, 5500W
-
Curtis 1268 dc Controller Assemblage for Electric Shuttle Bus 36-48V 5.5Kw
Product Description

Product Description
CURTIS Model | 1266A-5201 | ||||||
* Norminal Battery Voltage (Volts) | 48V (default setting) or 36V | ||||||
* Amarture 2 Minute Current Rating (amps) | 275 | ||||||
* Field 2 Minute Current Rating (amps) | 20 | ||||||
* PWM operating frequency | 16 kHz | ||||||
* Electrical isolation to heatsink | 500 V ac (minimum) | ||||||
Specifications:
* Proposed SepEx motor power rate: * 36V system: ≤ 3.8 kW
* 48V system: ≤ 4.7 kW
* simple motor connecting labels on assemblage
* easy installation with components mounted on a heat-sink aluminium alloy installation plate
* foot pedal accelerator (throttle), pre-wired for assemblage
* simple plug-in connctors
* Easy to install (1266A / 1266R CURTIS DC SepEx Controller Assemblage Installation Instruction (PDF format))
This 1266A-5201 controller assemblage is a completed electric vehicle DC Series Motor control system. The assemblage includes:
* controller
* main contactor
* fuses
* heat-sink aluminium alloy installation plate
* foot pedal accelerator (3-wire potentiometer throttle JSQD-DWK-003D)
* plug-in connectors
* installation (bolts, washes and nuts) kit Included
* harness (optional. If you need the harness, please check the speed sensor connector form of your motor.)
* Proposed SepEx motor power rate: * 36V system: ≤ 3.8 kW
* 48V system: ≤ 4.7 kW
* simple motor connecting labels on assemblage
* easy installation with components mounted on a heat-sink aluminium alloy installation plate
* foot pedal accelerator (throttle), pre-wired for assemblage
* simple plug-in connctors
* Easy to install (1266A / 1266R CURTIS DC SepEx Controller Assemblage Installation Instruction (PDF format))
This 1266A-5201 controller assemblage is a completed electric vehicle DC Series Motor control system. The assemblage includes:
* controller
* main contactor
* fuses
* heat-sink aluminium alloy installation plate
* foot pedal accelerator (3-wire potentiometer throttle JSQD-DWK-003D)
* plug-in connectors
* installation (bolts, washes and nuts) kit Included
* harness (optional. If you need the harness, please check the speed sensor connector form of your motor.)


Features Include:
* Regenerative braking, providing longer operation on a single battery charge and reducing motor brush wear and motor heating
* Adjustable brake rates, for smooth pedal-release braking
* Two user-selectable vehicle operating personalities, with vehicle top speed controlled and limited in each mode
* Motor parameters are programmable to match the characteristics of the specific motor being used
* Vehicle speed control is enhanced through feedback from a Hall effect speed sensor
* Anti-rollback function, providing improved control when throttle is released on hills
* Anti-stall function helps prevent motor commutator damage
* High pedal disable (HPD) and static return to off (SRO) interlocks prevent vehicle runaway at startup
* Complete diagnostics through CURTIS 1313-4331 Handheld Programmer or 1314 PC Programming Station and through the built-in
Status LED, for quick and easy testing, diagnostics, and parameter adjustment
* WalkAway™ braking feature limits any stopped or key-off rolling to a very low speed
* Auxiliary driver can be programmed for either an electromagnetic (EM) brake or a WalkAway™ relay
* Coil driver provides adjustable pull-in and holding voltages to WalkAway™ relay or EM brake
* Two fault outputs provide diagnostics to remotely mounted displays
* Reverse signal driver provides a low signal any time the vehicle is traveling in reverse
* Driver outputs are short circuit protected and provide built-in coil spike protection
* Brake/Drive Interlock meets ISO stopping distance requirements
* Warning buzzer sounds steady in reverse, intermittent during WalkAway™ braking
* Splash resistant plastic cover
* Meets or exceeds EEC fault detect requirements
* Regenerative braking, providing longer operation on a single battery charge and reducing motor brush wear and motor heating
* Adjustable brake rates, for smooth pedal-release braking
* Two user-selectable vehicle operating personalities, with vehicle top speed controlled and limited in each mode
* Motor parameters are programmable to match the characteristics of the specific motor being used
* Vehicle speed control is enhanced through feedback from a Hall effect speed sensor
* Anti-rollback function, providing improved control when throttle is released on hills
* Anti-stall function helps prevent motor commutator damage
* High pedal disable (HPD) and static return to off (SRO) interlocks prevent vehicle runaway at startup
* Complete diagnostics through CURTIS 1313-4331 Handheld Programmer or 1314 PC Programming Station and through the built-in
Status LED, for quick and easy testing, diagnostics, and parameter adjustment
* WalkAway™ braking feature limits any stopped or key-off rolling to a very low speed
* Auxiliary driver can be programmed for either an electromagnetic (EM) brake or a WalkAway™ relay
* Coil driver provides adjustable pull-in and holding voltages to WalkAway™ relay or EM brake
* Two fault outputs provide diagnostics to remotely mounted displays
* Reverse signal driver provides a low signal any time the vehicle is traveling in reverse
* Driver outputs are short circuit protected and provide built-in coil spike protection
* Brake/Drive Interlock meets ISO stopping distance requirements
* Warning buzzer sounds steady in reverse, intermittent during WalkAway™ braking
* Splash resistant plastic cover
* Meets or exceeds EEC fault detect requirements
