High Quality Three Dimensional Mixing Equipment For Chemical Food Pharma Industry
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
New Arrival 304 316 Stainless Steel Fine Pharmaceutical Grade Powder Three Dimensional Mixer
-
Food Vitamin Powder Mixer Pharmaceutical Chemical Stainless Steel Mixing Equipment
-
SINOPED Pharmaceutical Mixing Machine Powders Blender Mixer Industrial Mixing Machine
-
High Efficiency 3D Type Mini Lab Medicine Powder Mixing Machine / Industrial Scale Powder Mixer
-
Hot Sale Stainless Steel Medicine Powder 3D Type Blender Three Dimensional Mixer
-
China Semi Automatic Ultrasonic Aluminum Honey Grease Plastic Soft Tube Filling Sealing Machine Cream Cleanser Filler Machinery
Product Description
○ As a high efficient mixing equipment , this machine is used for highly uniform mixing of powdery and particle materials in such trades as pharmaceutical, food, chemical, light industry, machinery, electronics , mining and metallurgy, national defense industry and scientific research etc.
○ Material has no centrifugal force effect, specific gravity segregation, lamination and accumulation during mixing. Each omponent can be mixed under wide gap of weight roportion, mixing rate reaching up to 99.9%.
○ Loading coetticiency can reach 80%(40% for normal ones).
○ With compact structure, driving part of the equipment is step less controlled, featuring convenient operation.
○ Each part of drum is transited by arc and polished precisely, meeting the International requirements.
○ Loading coetticiency can reach 80%(40% for normal ones).
○ With compact structure, driving part of the equipment is step less controlled, featuring convenient operation.
○ Each part of drum is transited by arc and polished precisely, meeting the International requirements.
Principles
Mixing barrel is suspended on ends of driving and driven axles through two Y type universal joints that are crossing and vertical to each other in the space. When driving axle is driven to rotate, universal joint makes the barrel perform composite motion including horizontal moving, rotating and turning etc, in the space, by which, materials also performs 3-dimensional motion inside the barrel. Several kinds of materials inside the barrel flow, diffuse, penetrate each other and finally form uniform status.
Technical Parameters
Model | Cylinder volume | Maximum loading capacity | Maximum loading weight | Mixing time | Impeller speed | Mixing motor | Overall dimension (L × W × H) | Weight |
SWH-10 | 10L | 7L | 7kg | 0-99min | 0-22r/min | 0.18kw | 640*620*55mm | 150kg |
SWH-25 | 25L | 18L | 18kg | 0-99min | 0-15r/min | 0.55kw | 900*900*75mm | 150kg |
SWH-50 | 50L | 40L | 40kg | 0-99min | 0-15r/min | 0.75kw | 970*950*120mm | 300kg |
SWH-100 | 100L | 75L | 75kg | 0-99min | 0-15r/min | 1.5kw | 1200*1600*1500mm | 500kg |
SWH-200 | 200L | 160L | 160kg | 0-99min | 0-15r/min | 2.2kw | 1400*1800*1600mm | 800kg |
SWH-400 | 400L | 320L | 320kg | 0-99min | 0-12r/min | 4kw | 1700*2100*1850mm | 1200kg |
SWH-600 | 600L | 480L | 480kg | 0-99min | 0-11r/min | 5.5kw | 2100*2400*2250mm | 1500kg |
SWH-800 | 800L | 640L | 640kg | 0-99min | 0-10r/min | 7.5kw | 2200*2500*2300mm | 2000kg |
SWH-1000 | 1000L | 800L | 800kg | 0-99min | 0-10r/min | 7.5kw | 2280*2600*2500mm | 2500kg |
SWH-1200 | 1200L | 950L | 950kg | 0-99min | 0-10r/min | 11kw | 2400*2800*2550mm | 2800kg |
SWH-1500 | 1500L | 1200L | 1200kg | 0-99min | 0-10r/min | 15kw | 2500*3100*2600mm | 3000kg |
SWH-2000 | 2000L | 1600L | 1600kg | 0-99min | 0-9r/min | 18.5kw | 2800*3600*3200mm | 3800kg |
