injection molding machine
|
Item |
unit |
SZ-1300A |
||
|
Screw diameter |
mm |
35 |
40 |
45 |
|
Screw L/D ratio |
L/D |
24 |
21 |
18.7 |
|
Theoretical injection capacity |
cm3 |
173 |
226 |
286 |
|
Shot weight (PS) |
g |
158 |
206 |
260 |
|
Injection pressure |
MPa |
235 |
180 |
142 |
|
Injection stroke |
mm |
180 |
||
|
Screw speed |
rpm |
0-250 |
||
|
Heating power of barrel |
Kw |
9.2 |
||
|
Clamping force |
kn |
1300 |
||
|
Space between tie bars(H×V) |
mm |
420×420 |
||
|
Max. Mould height |
mm |
440 |
||
|
Min. mould height |
mm |
160 |
||
|
Opening stroke |
mm |
400 |
||
|
Distance between mould platens |
mm |
840 |
||
|
Ejector stroke |
mm |
100 |
||
|
Ejecting force |
kn |
31.4 |
||
|
Ejectors number |
pc |
5 |
||
|
Power of pump motor |
Kw |
13 |
||
|
Volume of oil tank |
L |
360 |
||
|
Dimension(L×W×H) |
m |
4.7×1.25×1.85 |
||
|
weight |
ton |
4.3 |
||
Advantages
- Equipped with high efficient low noise and sensitive respond energy-saving system,it makes the hydraulic output always match with the system required power,without extra energy lose via high pressure throttling or paring with traditional machines with fixed oil pump,new machines can save 25-80%energy,meanwhile reduce the oil working temperature to lengthen its service life
- Low carbonate,save energy and protect environment,and gain the benefit of society and economic.
SERVO System
After receiving the pressure and flow instuction from computer controler,the servo driver will compare it with the actual pressure and flow feedback,and rectity the difference by controling the rotating speed of the sevo motor.Inthis way,the control ofinjection molding is not only acurate but also fast,and the repeatabillty of the products high as well.
Injection Machine details
CLAMPING UNIT of injection molding machine
INJECTION UNIT of injection molding machine
HYDRAULIC UNIT of injection molding machine
CONTORL UNIT of injection molding machine
Auxiliary Equipments of injection molding machine
