Home > Products > Steel Coil > 9208 4x10 Bis Certificate Ppgi Prepainted Galvanized Factory
9208 4x10 Bis Certificate Ppgi Prepainted Galvanized Factory
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Ral7021 G300 Bis Certificate Ppgi Prepainted Galvanized
-
China Primary Ray9003 Ral 7014color Coating Ppgi
-
Dx51d Z275 Z350 Hot Dipped Galvanized Steel Coil 0.5mm 1219mm
-
Hot Dipped Galvanized Steel in Coil 0.5mm 1219mm G40 Coat
-
Dx51d Z275 Z350 Hot-dip Galvanized Steel in Coil ss 33 Class 1
-
Dx51d Z275 Z350 Hot-dip Galvanized Steel in Coil 0.0183 in Thick
Product Description
| Item name | 9208 4x10 bis certificate ppgi prepainted galvanized factory | ||
| Grade | DX51D+Z | S250GD+Z | |
| SGCC | DX52D+Z | S280GD+Z | |
| SGCD | DX53D+Z | S350GD+Z | |
| SGCE | DX54D+Z | S550GD+Z | |
| DX56D+Z | |||
| Thickness | 0.12 ~ 3.00 mm (cold rolled) | ||
| 1.20 ~ 4.60 mm (Hot-rolled ) | |||
| Width | 10 - 600 mm (strip) | ||
| 600 - 1250 mm (coil) | |||
| Tolerance | Thickness: ±0.01 mm | ||
| Width: ±2 mm | |||
| Coil ID | 508 mm - 610 mm | ||
| Coil weight | 3 - 8 ton or as client requirement. | ||
| Zinc coating | 30g - 275g / m2 | ||
| Spangle | Big spangle,Regular spangle,Mini spangle,Zero spangle | ||
| Surface treatment | Oil,Passivation, Chromated, Skin-passed, Anti-finger Print | ||
| HS code | code 72104900 | ||
| Application | Widely used in road, railway, civil construction, water conservancy construction; all kinds of machinery, electrical appliances, window protection and aquaculture, etc. | ||
| Package | Standard export package (Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet) | ||
| Delivery time | Within 15 workdays after deposit received | ||
| Remarks | Insurance per to Contract terms; MTC will be handed on with shipping documents; We accept the third party certificatation test. |
||
| STEEL GRADE | CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF | COATING | ||||||
| C | Si | Mn | S | P | T.S | Y.S | E.L | COATING | ||
| x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=0 180° | G/M² | |
| JIS G3302 SGCC | 12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK | Z60-150 |
| JIS G3302 SGCH | 12 | 10 | 21 | 18 | 8 | 680 | 650 | 20 | OK | Z60-150 |
| ASTM A653 CS.B | 29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK | Z60-275 |
| DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK | Z60-275 |
| G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK | Z60-275 |
