DN15 1/2 inch 1/2'' water flow control ball valve electronic shut off valve washing machine ball valve
- 1000 per Month
- T/T Credit Card
You May Like
-
CWX-15N stainless steel brass BSP NPT motorized flow control valve 12V electric actuator ball valve cwx-15
-
CWX-15N stainless steel brass BSP NPT motorized flow control valve cwx-15q motorized ball valve
-
6NM Torque 2 Way electric motor ball valve for Industrial automation small devices, motorized actuator valve
-
1/2 ,3/4 and 1 inch Gas Water Brass SS304 DC 12V Electric Control Motorized Ball Valve
-
auto shut off valve for water leak water leak detector with shut off valve with alarm water leak detector with shut off valve
-
motorized ball valve CR01 CR02 DC3.6-6V DC12V CWX-15N brass DN25 3v 1 inch motorized water ball valve
Product Description
For other specifications, please consult the sales representative.
1. Quick open/ close action, 3s-5s.
2. Low noise, reliable performance.
3. Long service life - more than 50000 on/off cycles.
4.Power cuts off automatically when the valve is fully open or closed to prevent overheating and make it eco-friendly.
5. Compact structure and smart shape.
6. Float ball structure ensures simple structure and good sealing performance.
7. A great alternative to solenoid valves for projects where a valve needs to stay open for most of the time.
1. Water treatment system, water-saving system, water equipment.
2. Small industrial equipment for automatic control.
3. Good replacement for solenoid valve, particularly when solenoid valve cannot work reliably.
4. Irrigation system, timing humidifying, timing of drainage of air compressor.
5. Solar hot water project.
6. HVAC.
Product Model | Rated Voltage | Working current | Output torque | Open/close time | Size |
CWX-15Q | DC3-6V DC12V AC/DC9-24V AC220V AC85-265V | Max100mA (CR04 except Max150mA) | Max1.5NM | <3s | DN8-DN20 |
CWX-15N | Max2.0NM | <5s | DN8-DN32 | ||
Working pressure | Power | Medium temperature | Control mode | IP Grade | Special function |
Max1.0Mpa | <3W | 0-90℃ | CR01 CR02 CR02+ CR03 CR03A CR04 CR05 | IP65 | CR01 CR02 CR03 CR04(with signal feedback) |
Brass
| Connection | Sizes | d | H | L |
Both female thread Full-port | DN8 | 8 | 46 | 31 | |
DN15 | 15 | 57 | 38 | ||
DN20 | 20 | 71 | 45 | ||
DN25 | 23.5 | 72 | 49 | ||
Both female thread Reduce-port | DN10 | 8 | 46 | 31 | |
DN20 | 15 | 66 | 38 | ||
DN25 | 20 | 72 | 47 | ||
DN32 | 25 | 86 | 60 | ||
Vertical Three-way | DN15 | 12 | 63 | 49 | |
DN20 | 15 | 66 | 53 | ||
Female-male thread | DN15 | 15 | 63 | 38 | |
DN20 | 15 | 66 | 38 | ||
DN32 | 20 | 76 | 50 | ||
Both male thread | DN15 | 15 | 68 | 38 | |
SS304/316 | Both female thread | DN8 | 8 | 46 | 31 |
DN10 | 8 | 46 | 30.5 | ||
DN15 | 15 | 55 | 38 | ||
DN20 | 15 | 63 | 39 | ||
DN20 | 20 | 71 | 45 | ||
DN25 | 20 | 75 | 47 | ||
DN25 | 25 | 72 | 49 |
1. Are you manufacturer or trading company?
We are manufacturer, we have been in electric valve industry for more than 10 years. So we have advantage in price. We also could do OEM.
2. What's the payment method?
T/T,Paypal,Western Union, Moneygram,Aliexpress, L/C ect.
3.What's your Minimum Order Quantity (MOQ)?
Our MOQ is 1piece.
4. What about the delivery time?
Sample orders need about 3 working days, for larger order, it denpends on the quantity.
5.Would you offer a discount if l have a large order?
A; Yes, we could offer different discounts according to the order quantity.
6.Where is the factory located?
Tianjin city and welcome to visit our factory.
