Home > Packaging & Printing > Printing Machinery > Screen Printer > Automatic Screen Wash-Out Machine

Automatic Screen Wash-Out Machine

Shanghai Shameng Precision Machinery Manufacturing Co. Ltd
Automatic Screen Wash-Out Machine thumbnail-1
Automatic Screen Wash-Out Machine thumbnail-2
Automatic Screen Wash-Out Machine thumbnail-3
Automatic Screen Wash-Out Machine photo-1
Automatic Screen Wash-Out Machine photo-2
Automatic Screen Wash-Out Machine photo-3
US$ 10000 - 13000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
shameng
Place of Origin:
China
Model Number:
SM-860SA
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
45 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name shameng
Place of Origin China
Model Number SM-860SA
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Automatic Grade Semi-Automatic
Gross Power 2KW
Color & Page Single Color

SM-1000CB
Max.Frame Size(outer)
1000 × 1000mm
Min.Frame Size(outer)
400 × 400mm
Water Remover
Hybrid Air Knife
Pump Max.Capacity
15000ℓ/hr(1HP Type)
Water Heater
220V × 2kW × 1EA
Nozzle Speed
5 ~ 30m/sec
Reciprocation
6 ~ 15sec/cycle
Blower Motor
3Hp High Pressure Fan
Driving Motor
A.C Geard 200W × 1/10
Elec.Source
220(380)V × 3p × 6kW
Weight
Approx.780kg
Dimension(W × D × H)
2500 × 1200 × 2200mm


* Special specification is made to order.
* Appearance and specifications in this homepage are subject to change without notice.

  Characteristic • Simultaneous spray on the both sides.
• Stainless material prevents internal corrosion and allows long       durability.
• Water pressure adjustable according to a type of the screen.
• Saving water supply by using the filtering circulation method.
• Indication of water pressure makes the standard operations easy.
• Hybrid air knife shortens the drying time.

Product Tags: Automatic Screen Wash-Out Machine , Screen Wash-Out Machine
