Calcium Fluoride Lenses
- 100 Piece / Pieces per Month
- Nanjing
- T/T L/C
- 45 days
- Cooling type medium wave infrared camera thermal image detector lens cooling thermal imaging movement infrared camera
- Refrigerated medium wave short wave infrared high definition thermal imaging camera
- Color low-light night vision Full color low-light color night vision Full color night vision low-light color camera
- 18-54/50-90/25-100/30-150mm thermal imaging electric continuous zoom lens 1280 * 1024
- Customized/OEM infrared thermal imaging lens with fixed focus/zoom, various focal lengths, standard definition or high-definition 1280
- 25/35/50/75/100/150mm long wave infrared lens uncooled thermal image movement fixed focus/zoom
Product Details
Brand Name: | Hyperion Optics | Place of Origin: | China | Compatible Brand: | Other, Hyperion Optics |
Product Description
Hyperion Optics supplies uncoated 1/2 inch and 1 inch in diameter Calcium Fluoride (CaF2) lenses. Please talk to our technicians for your custom requirement. We are also able to provide coated products with AR coating through 1.65µm or 2-5µm.
CaF2 has high transmission rate through 0.18-8.0 microns, used for UV and IR spectral high transmission applications. With its outstanding laser power damage threshold CaF2 lenses also are widely used under excimer laser environment. Its refractive index is comparatively low from 180nm up to 8.0 microns, ranges from 1.35 to 1.51. CaF2 has low dispersion, in visible wavelength applications, it shows superior vivid and exquisite imaging performance compared to regular optical glasses.
However, Calcium Fluoride components are difficult to manufacture in actual production. The material itself is soft and easy to leave fabrication marks and scratches on the polished surfaces. At Hyperion Optics, with our decade experience of CaF2 production, we have outstanding surface accuracy and cosmetic control method, our typical surface quality grade is 40-20 according to MIL-C-13830A.
Calcium Fluoride | COMMERCIAL GRADE | FACTORY STANDARD | PRECISION GRADE |
Diameter Tolerance(mm) | +0/-0.05 | +0/-0.03 | +0/-0.02 |
Center Thickness(mm) | ±0.01 | ±0.03 | ±0.025 |
Wedge (Arc min) | 6 | <3 | <1 |
Cosmetic(MIL-C-13830A) | 100-80 | 60-40 | 40-20 |
Figure Tolerance inλ(Pow/irreg) | 2.5 - 1.5 | 2 - 1 | 1/0.25 |
Coating (T% avg) | Depends on Different Working Wavelength | ||
Materials | Calcium Fluoride |
Hyperion Optics is a leading optics supplier, we provide parabolic mirror design, parabolic reflectors for sale, optical assembly manufacturing and etc. Contact us to know the details calcium fluoride ir windows or caf2 transmission.
