TM-600 VDSL VDSL2 Tester for xDSL Line Test and Maintenance Tools ADSL VDSL2 DMM

Attention:This product is basic version.It does not include the following functions:

Optical Power Meter (Optional)

Visual Fault Locator (Optional)

Tone Tracker (Optional)

TDR Cable Fault Locator (Optional)

Specifications:
- TM-600 VDSL tester specially designed for xDSL line test (xDSL include: ADSL, ADSL2, ADSL2+, READSL, VDSL2 etc) and maintenance It provides xDSL test, PPPoE dial test, DMM test, Modem emulation, line voltage indication and so on.
- It is one multifunction tester with smart size, true color LCD and powerful management software as well as the 6600mah rechargeable battery etc
- This is the basic version,with  ADSL/VDSL/DMM functions.

Key Features:
Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2
Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)
Supports Modem emulation and simulating login to Internet
Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)
Supports all multi-protocol, PPPoE / PPPoA (LLC or VC-MUX)
Connects to CO via alligator clip or RJ11
Rechargeable Li-ion Battery
Beep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)
Data memory fuction
LCD display, Menu operation
Auto shut off if no any operation on keyboard
Compliant with all known DSLAMs
Software management
Simple, portable and money-saved

Functions:
- DSL Physical layer test
- Modem Emulation (Replace the user Modem completely)
- PPPoE Dialing (RFC1683,RFC2684,RFC2516)
- PPPoA Dialing (RFC2364)
- Telephone Function
- DMM Test
- Ping Function (WAN & LAN)
- Data upload to computer and software management
- Setup system parameter: backlight time, shut off automatically time without operation, press tone,
- Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.
- Check dangerous voltage

ADSL2+:
Standards: ITU G.992.1(G.dmt),
ITU G.992.2(G.lite),
ITU G.994.1(G.hs),
ANSI T1.413 issue #2,
ITU G.992.5(ADSL2+)Annex L,
Up channel rate:0~1.2Mbps
Down channel rate:0~24Mbps
Up/Down attenuation:0~63.5dB
Up/Down noise margin:0~32dB
Output power:Available
Error test     CRC,FEC,HEC,NCD,LOS
Display DSL connect mode:Available
Display channel bit map:Available

ADSL:
Standards
ITU G.992.1 (G.dmt)
ITU G.992.2(G.lite)
ITU G.994.1(G.hs)
ANSI T1.413 Issue # 2
Up channel rate:0~1Mbps
Down channel rate:0~8Mbps
Up/Down attenuation:0~63.5dB
Up/Down noise margin:0~32dB
Output power:Available
Error test     LCD,OCD,HEC,FEC,CRC
Display DSL connect mode:Available
Display channel bit map:Available

VDSL2:
Be compatible with ADSL2+, ADSL standard.
DSL line attenuation
DSL line noise margin
DSL line up/down channel speed (Inter/Fast mode)
DSL line up/down maximum rate
DMT sub channel bit number: 0~15, and each sub channel frequency points
DSL line error number (CRC, HEC, FEC, LCD, OCD)
DSL line local output power
DSLAM information
Error Code Second
Impulse Noise Protection (INP)
Support 7 VDSL2 profiles: profile 8a, 8b, 8c, 8d, 12a, 12b, 17a

DMM Test:
DC voltage (V):0~400
AC voltage (V):0~400
Loop resistance(Ω):0~20000
Capacitance (nF):0~1000
Insulation resistance (MΩ):0~50

General Specification:
- Power Supply:Internal Rechargeable 7200mAH Li-ion battery
- Battery Duration:4 to 5 hours
- Working temperature:10-40°C
- Working moisture:5%-90%
-Auto Test the cable fault distance (Cable Break/ Cable Mix)
- Test Range:<2.5km
- Dead Zone:<1m
- Resolution Rate:1m
 - Dimensions:170mm×70mm×52mm
- Weight:<0.6kg

Package List:
- 1 x TM600 VDSL Tester Kit

Detail photo
