Description:

The battery testers of this series are designed for battery testing and cell grading and can be adopted to a wide range of batteries like Lead-Acid, Li-Fe and Li-Ion.

Range of application:
- The EBC-X battery testers can be used for testing and grading a wide range of batteries like LiFe,LiPo, Pb and etc.
- We provide testers of three categories: high power testers, which cover a range of 5V20A-200A and allow you to test batteries with high capacities,power batteries and super capacitors;standard testers with a range of 5V5A-10A,and low power testers of 5V1mA-1000mA including button cells and other batteries with low capacities.We also provide customaries testers to meet your special needs.

Hardware characteristics:
- The testing system consists of upper computer (PC) and lower computer(control circuit unit) and ensure reliable tests.
- Each channel works independently and parameters can be set individually in charging and discharging.The system adopts modularized hardwires which are easy to extend and maintain.The EBC-X testers connect with independent clamps which can be replaced in testing different batteries.
Power and channel indicators on testers allow you to read working state easily.

Software characteristics:

In the software you can read working state,voltage,current,capacity,energy,cycle number and etc.It allows you to set parameters up to 10 steps and for 1000 cycles.Each channel separates from the others and you can select single channel or multi channels.Charging and discharging current,voltage and capacity display in curves which supports for later analization.The software supports automatic data recording and parameter
calibration.

Parameter:
- Model:EBC-X
- Voltage range:0~4.500V
- Voltage accuracy:0.1%+-0.003V
- Current range:0.1~10A
- Current accuracy:0.2%+-0.005A
- Discharge mode:CC
- Discharge termination:Time/Cut-off current/Manual
- Charge mode:CC-CV
- Charge termination:Time/Cut-off current/Manual
- Testing channel:8 separate channels
- Heat Disspation:fan
- Power supply:200~240V AC
- Packed Size:485x410x140mm(with battery holder)
- Packed weight:14kg

Package List:
- 1 x EBC-X Battery Capacity Tester(with battery holder)
- 1 x On-line line
- 1 x Test lines
- 1 x Power cord
- 1 x User manual

Note: AC220V/110V,optional.Please leave a message.

Attention: Not support testing batteries in series.
