XYX-3 Diesel Type 200m Depth Underground Rotary Bore Water Well Drilling Machine for Sales

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

XYX-3 Diesel type 200m depth underground rotary bore water well drilling machine for sales

Product Description

1.Full hydraulic system operation
2.Six wheels mounted .Convenient For Transportation
3.Multipurpose and trailer mounted rig

Technical data

Drilling depth		100, 250, 300, 600m
Drilling diameter		300 200 150 75mm
Hole diameter		300mm
Final hole diameter		75mm
Diameter of the drilling rod		60mm
dip angle of hole		90°-65°
vertical shaft
Vertical rotation speed of vertical axis		30-1050rpm
Vertical reversal speed		29-137rpm
Vertical axis stroke		560mm
Diameter of shaft inner hole		96mm
Lift capacity		60KN
Main Windlass(Hydraulic device)
Single rope lifting speed	0-45m/Min
Wire rope diameter	14mm
Band width	90mm
Drum diameter	300mm
Single rope lift capacity	40KN
Secondary Windlass
Drum diameter	140mm
Wire rope diameter	6mm
Drum volume	450m
Mud pump
Mud pump	BW-250 Horizontal three cylinder
Flow rate	250L/Min
Working pressure	7Mpa
Water input diameter	75mm
Gear oil pump
Double oil pump
Front flow rate and pressure
Back flow rate and pressure
Rig power
Diesel	4 cylinder
Motor	Y180L-4 22KW
Wheel chassis length	2.6m
Wheel chassis width	2m
Wheel chassis height	0.6m
