MS1UI7C Single Phase ac Panel Lcd Electric Voltmeter Ammeter Digital Wattmeter
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Volts Amps KW HZ Watt Hour TCP Electric Digital Power Meter RS485
-
MS3E7C Smart Digital Panel Three Phase Rs485 Remote for Electric Power Meter
-
Multi Function Three Phase Digital Panel Current Voltage Frequency Power Meter
-
MS3UI5C 3 Phase IOT Current Voltage Frequency Energy Monitoring Power Meter
-
Smart Multifunction Three Phase Digital AC Kwh Meter Energy Meter
-
3-Phase Digital Electric Modbus Current Voltage Frequency Power Meter
Product Description
Product Description
MS1UI7C single phase ac panel lcd electric digital wattmeter voltmeter ammeter
Series of DZ81-MS Single-phase Power Meters are used for measuring and monitoring the power distribution system. This series combines the measurement, the analysis and the operation together. People can check the figure of current or voltage by using the keys on the meter, which makes the information become clearer, and the operation become easier.
Functions
• Measuring all parameters: three phase voltage, current, line voltage, voltage unbalance, current unbalance, active power, reactive power, apparent power, power factor, frequency,active energy, reactive energy
• Standard CT, PT or voltage direct connected, suitable for various wiring modes under high or low pressure environment
• SOE records accurate to milliseconds
• 1 interface* RS485/Lora (optional)
• Modbus RTU communication protocol, DL/T645 (optional)
• 4 DI
• 2 DO (optional)
• 3 AO (Analog Output)
• 1* programmable energy pulse output
• LED display
Product Parameters
| Accuracy Class | Voltage: 0.2; Current: 0.2; Frequency: 0.05 Hz; Power Factor: 0.5 | |
| Active Power: 0.5; Reactive Power: 0.5; Apparent Power: 0.5 | ||
| Active Energy: 0.5S/1; Reactive Energy: 2 | ||
| Input | Rated Value | Voltage: 100V/400V; Current: 1A/5A |
| Overload | Voltage: Sustained Overload: 1.2 times of the rated value Momentary Overload: 2 times of the rated value Current: Sustained Overload: 1.2 times of the rated value Momentary Overload: 10 times of the rated value | |
| Frequency | 45-60HZ | |
| Functional Module | Interface | 1 RS485; Modbus RTU Integration; Baud Rate: 1200-19200bps |
| Power Supply | Working Range | AC: 85-265V; DC: 85-300V |
| Consumption | < 3W | |
| Working Condition | Temperature | Operating: -20℃ ~+70℃, Storage: -40℃ ~+80℃ |
| Humidity | Relative Humidity: <93% Place Without Corrosive Gas | |
| Altitude | <4000m | |
| Installation | Panel installation, Cut-Out Size: 68×68(mm) | |
