Product Description
Product Description
MS3UI5C Heyuan three phase power quality analyser electric measurement
Features:
• Measuring all parameters: three phase voltage, current, line voltage, zero-sequence current, zero-sequence voltage, voltage unbalance, current unbalance, active power, reactive power, apparent power, power factor, frequency, four-quadrant electric energy, active energy, reactive energy bidirectional active energy, bidirectional reactive energy.
• Standard CT, PT or voltage direct connected, suitable for various wiring modes under high or low pressure environment
• Analysis of current/voltage harmonic (2-31times)
• Multi tariff (optional), available for querying past 12 months' energy
• SOE records accurate to milliseconds
• Real time clock
• 1 interface* RS485/Lora (optional)
• Modbus RTU communication protocol, DL/T645 (optional)
• 4 DI (optional)
• 2 DO (optional)
• Voltage qualified rate
• 1* programmable energy pulse output
• LCD display
| Accuracy Class | Voltage: 0.2; Current: 0.2; Frequency: 0.05 Hz; Power Factor: 0.5 | |
| Active Power: 0.5; Reactive Power: 0.5; Apparent Power: 0.5 | ||
| Active Energy: 0.5S/1; Reactive Energy: 2 | ||
| Input | Rated Value | Voltage: 100V/400V; Current: 1A/5A |
| Overload | Voltage: Sustained Overload: 1.2 times of the rated value Momentary Overload: 2 times of the rated value Current: Sustained Overload: 1.2 times of the rated value Momentary Overload: 10 times of the rated value | |
| Frequency | 45-60Hz | |
| Functional Module | Interface | 1 RS485; Modbus RTU Integration; Baud Rate: 1200-19200 |
| Power Supply | Working Range | AC: 85-265V; DC: 85-300V |
| Consumption | < 3W | |
| Working Condition | Temperature | Operating: -20℃~+70℃ Storage: -40℃~+80℃ |
| Humidity | Relative Humidity:<93% (place without corrosive gas) | |
| Altitude | <4000m | |
