3 Phase Watt Hour Din Rail Mount Voltage Ampere Energy Meter
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Small Three Phase CT RS485 Smart Electronic Kwh Watt Power Meter
-
3 Phase 4 Wire Din Rail RS485 Electronic CT Kilowatt Energy Meter
-
DZS310 Three Phase Bi Directional Din Modbus Electronic Kwh Power Meter
-
Din Rail Three Phase Bidirectional MODBUS RTU Eelectronic Energy Meter
-
Three Phase Din Modbus Electronic Bi Directional Kilowatt Energy Meter
-
Three Phase Electronic Mobus Energy Kwh Din Rail Power Meter
Product Description
Products Description
3 Phase Watt Hour Din Rail Mount Voltage Ampere Energy Meter
With internationally cutting-edge imported metering IC solutions, we launched 27circuits smart meters with efficient and stable metering performance for all electrical parameters. Matched with Heyuan Cloud Platform Managing System, it can provide remote stable and reliable data and ensures efficient energy management and electrical safety monitoring.
Features:
• Monitoring up to 9 three-phase channels or 27 single-phase channels and measuring all parameters: three phase voltage, current,
line voltage, zero-sequence current , zero-sequence voltage, active power, reactive power, power factor, frequency, active energy,
reactive energy from 9 circuits.
• Standard CT, PT or voltage direct connected, suitable for various wiring modes under high or low pressure environment
• 2* RS485/Lora LoraWan (optional) • Modbus RTU communication protocol, DL/T645 (optional)
• 4 DI
• 2 DO (optional)
• 2* programmable energy pulse output
• LCD display
line voltage, zero-sequence current , zero-sequence voltage, active power, reactive power, power factor, frequency, active energy,
reactive energy from 9 circuits.
• Standard CT, PT or voltage direct connected, suitable for various wiring modes under high or low pressure environment
• 2* RS485/Lora LoraWan (optional) • Modbus RTU communication protocol, DL/T645 (optional)
• 4 DI
• 2 DO (optional)
• 2* programmable energy pulse output
• LCD display
Product Paramenters
Technical Parameters-DZS900 | ||||
Accuracy Class | Voltage: 0.2; Current: 0.2; Frequency: 0.05 Hz; Power Factor: 0.5 | |||
Active Power: 0.5; Reactive Power: 0.5; Apparent Power: 0.5 | ||||
Active Energy: 0.5S/1; Reactive Energy: 2 | ||||
Inputs | Rated Value | Voltage: 100 V/400 V Current: 20mA | ||
Overload | Voltage: Sustained Overload: 1.2 times of the rated value Momentary Overload: 2 times of the rated value Current: Sustained Overload: 1.2 times of the rated value Momentary Overload: 10 times of the rated value | |||
Frequency | 45-60Hz | |||
Functional Module | Pulse Outputs | 2 | ||
Interface | 2* RS485; Modbus RTU communication protocol; Baud rate: 1200-19200bps | |||
Power Supply | Working Range | AC: 85-265V; DC: 85-300V | ||
Consumption | < 3W | |||
Working Condition | Temperature | Operating: -20°C~+65°C. Storage: -40°C~ +85°C | ||
Humidity | Relative Humidity: < 93% (place without corrosive gas) | |||
Altitude | <4000m | |||
Dimensions: | 210×100×45mm | |||
