4G WIFI Ethernet Smart meter data collector logger iot gateway industri rtu to modbus tcp gateway
KPM200 series Smart meter data collector logger iot gateway industri rtu to modbus tcp gateway is an important part of the intelligent distribution automation system to complete the power distribution room microcomputer protection,automatic devices,monitoring and other intelligent devices and computer systems,power grid automation system to achieve the exchange of information between the far station information to the host Exchange and network exchange,thus forming a fully decentralized RTU communication system.
KPM202 2 RS485 port communication rtu to modbus tcp gateway
KPM204 4 RS485 industri rtu to modbus tcp gateway
Function Features
1.Industrial grade Contex-A8 processor,800MHz frequency.
2.512MB DDR3 SDRAM,512Mflash.
3.Support 2/4-way high-speed 10/100M independent network interface.
4.Support 4/16-way RS485 serial communication interface.
5.Built-in real-time clock (RTC),temperature sensor and independent hardware encryption circuit to protect user IP.
6.Built-rich communication protocol library to support the electricity IEC60870-101/103/104 protocol,support ProfiNET,EtherNet,BACnet,SNPx and other communication protocols.
9.Built-in WEB server,support for remote development,configuration,commissioning and maintenance.
10.Achieve communication management,data gateway,data forwarding,protocol conversion,pre-processing and other functions.
11.CAN interface bidirectional optical isolation CAN2.0 interface standard.
12.Support all the way debug serial port,as well as WIFI wireless LAN/GPRS/3G/4G remote communications and other extensions.
13.Expandable 4-128G TF memory card.
14.Rugged metal shell and internal circuit "three defenses" treatment,especially for the harsh environment on site.
Technical specification
| Function type | ||
| Working power | Rated voltage | 6-24 VDC, 12 VDC recommended |
| Power consumption | <3VA | |
| Capacity index | Network interface | 1 * 10/100M RJ45 interface |
| Serial port | 2 * RS485 port +1 * RS232 | |
| Communication master station protocols | <16/pc | |
| Serial port rate | 300bps to 38.4kbps, programmable | |
| Transmission mode | Full or half duplex | |
| Performance index | Dual machine switching time | <5s |
| MTBF | >50000h | |
| Status indication | Panel LED, reflecting the serial port data transmission and reception status | |
| Protocol | Standard protocol | IEC60870-5-101/103/104,MODBUS,CDT, |
| Special protocol | DNP3.0 and other over 30 protocols,can be developed according to on site needs | |
| EMC | Fast pulse group immunity | IEC61000-4-5, level 3 |
| Surge immunity | IEC61000-4-2, level 3 | |
| Electrostatic immunity | IEC61000-4-4, level 3 | |
| Working environment | Ambient temperature | -25℃~+70℃ |
| Relative temperature | 5%~95%, no condation | |
| Storage temperature | -30℃~+75℃ | |
| Mounting size | Mounting type | Wall mounted |
| Size L×W×H | 120mm×75mm×30mm |
