Product Description

Product Overview

KPM53 power meter data logger 3 Phase Digital three phase power quality and energy analyzers

KPM53 series 3 Phase Digital three phase power quality and energy analyzers is with accurate measurement of power parameters,the instrument uses advanced ARM processor and digital signal processing technology designed from the set of three-phase electrical parameters measurement,display, power statistics,power quality analysis,digital input/Output and network communications in one;with high precision,strong isolation,stable performance,anti-interference ability and a little; the instrument also has a very strong expansion capabilities,such as monitoring of external switching action,4-20mA analog output,but also The network management of the instrument can be realized through RS-485/Modbus communication protocol.

FEATURES AT A GLANCE

1.Alternative analog pointer table.

2.Display and control of electrical parameters in mid-low voltage distribution System.

3.Collect energy consumption data that cost center analysis needs.

4.Green building or DC.

Details Images

Product Paramenters

Technical Parameters
KPM 53 3 Phase Digital three phase power quality and energy analyzers
Accuracy Class			Voltage: 0.2; Current: 0.2; Frequency: 0.02 Hz; Power Factor: 0.5
				Active Power: 0.5S; Reactive Power: 2.0
				Active Energy: 0.5S; Reactive Energy: 2.0
Input	Rated Value	Voltage: 57.7/100V, 220/380V,380/660V Current: 1A(0~1.2A), 5A (0~6A)

		Overload	Voltage: Sustained Overload: 1.2 times of the rated value
				Momentary Overload: 2 times of the rated value, allows 1s
				Current: Sustained Overload: 1.2 times of the rated value
				Momentary Overload: 20 times of the rated value, allows 1s
		Frequency	45-60Hz
Functional Module	Pulse Output	1
Functional Module		Interface	1*RS485; Modbus RTU protocol; Baud Rate: 1200-38400 bps
Power Supply	Working Range	AC: 85-265V; DC: 80-300V
Power Supply		Consumption	< 3VA
Working Condition	Temperature	Operating: -25°C~+70°C. Storage: -30°C~ +75°C
		Humidity	5%~95% No condensation
		Altitude	<4000m
Dimensions:			96×96×88mm

Certifications

Company Profile

R&D Dept.

More than 40 R&D engineer, including software team, hardware team.

Production shop

Lean production management， guarantee product delivery and quality.

Sales office

International trade and deomestic sales for globle market.

FAQ
