MP-MP-A Oil Differential Pressure Controller

Differential oil pressure controllers MP 54 and MP 55 are safety switches used to prevent low oil pressure in refrigeration compressors. If the oil pressure drops below the set value, after a certain time interval, the oil pressure differential controller will act to stop the compressor.

MP 55 pressure controller with adjustable differential pressure, low differential pressure

Control voltage: 230 V or 115 V a.c. or d.c.

Allowable voltage fluctuation: +10 - -15%

Maximum working pressure = 17 bar

Maximum test pressure = 22 bar

Temperature compensation

Time Relay Temperature Compensation Range -40 - +60°C

Spiral lead entry: Pg 13.5

Maximum allowable temperature: 100°C

Package: IP 20 to IEC 529.

characteristic

value

Type MP55

Mass [kg] 0.740 [kg]

Adjustment Pressure drops to set value to cut off

Ambient temperature [°C] -40 - 60 °C

Ambient temperature [°F] -40 - 140 °F

Ammonia application no

Certification CCC

Certification CE

Certified GL

Complete set of parts Timing relay

Contact function SPDT

Contact rating AC15=2 A, 250 V

Contact rating DC13=0.2 A, 250 V

Differential range [bar] 0,30 - 4,50 bar

Enclosure rating IP20

Factory setting [bar] 0,65 bar

dim light no

Same product 060B101166

Max. test pressure [bar] Pe 22,0 bar

Max. working pressure [bar] Pe 17,0 bar

Max. Working Pressure [psig] Pe 245,0 psig

Operating range LP side [bar] Pe -1 - 12 bar

Operating range LP side [psig]Pe -15 - 175 psig

Packing format Multi pack

Quantity per standard package 21 pc

Start relay release time 60 s

Reset function Minimum
