Product Description
Products Description
The high voltage power cables contained within this datasheet are suitable for the primary distribution of power up to a maximum
network voltage of 110kV. Suitable for locations where mechanical protection is afforded by other means and where the additional
protection of a moisture barrier has been determined not to be necessary, see 2XS(FL)2Y and A2XS(FL)2Y.
Specifications
NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | ELECTRICAL PROTECTION mm2 | NOMINAL DIAMETER OF CONDUCTOR mm | NOMINAL THICKNESS OF INSULATION mm | NOMINAL DIAMETER OVER INSULATION mm | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km | MINIMUM BENDING RADIUS (FIXED) mm | MINIMUM BENDING RADIUS (FIXED) mm |
1 | 150 | 95 | 14.1 | 18 | 54.9 | 64.5 | 3995 | 970 | 4.5 |
1 | 185 | 95 | 15.7 | 17 | 54.5 | 64.1 | 4026 | 960 | 5.5 |
1 | 240 | 95 | 18 | 16 | 54.8 | 64.4 | 4156 | 970 | 7.2 |
1 | 300 | 95 | 20.3 | 15 | 55.1 | 64.7 | 4263 | 1000 | 9 |
1 | 400 | 95 | 23 | 15 | 57.6 | 67.4 | 4746 | 1010 | 12 |
1 | 500 | 95 | 26.5 | 15 | 61.3 | 71.3 | 5287 | 1070 | 15 |
1 | 630 | 95 | 30.3 | 15 | 64.5 | 74.8 | 5908 | 1200 | 18.9 |
1 | 800 | 95 | 36.9 | 15 | 71.8 | 82.6 | 6925 | 1240 | 24 |
1 | 1000 | 95 | 37.9 | 15 | 72.8 | 84 | 7409 | 1260 | 30 |
1 | 1200* | 95 | 44 | 15 | 78 | 90 | 8010 | 1350 | 36 |
Company Profile
Hunan Guanglian Optoelectronics Technology Co., Ltd. was established in 2009. The company is located in China Changsha, Hunan. The company is an AAA credit enterprise and a national high-tech enterprise. The company has passed ISO9001 quality certification, TLC product certification, management system certification, power cable access license, Coal safety certification, and has obtained a number of technical patents, and has a comprehensive and unique solution in the national grid optical fiber transmission project. If you need visit our factory , we will meet you at the airport or train station.
lso we can offer other service. Custom Merchandise:we can make cable as your need include the color ,size and so on.we also offer OEM .Complete Course Tracking:we can offer you the service from the business begin to you get the cable and use it
Cable sample : we can offer the sample free
