IID Series Mini Circuit Breaker 6A-40A 50A-60A AC230/400 50/60Hz Large Stock 1P/2P/3P

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

1. Application

The RCCB is suitable to the circuit of AC 50/60Hz.rated voltage 230V for 2 poles and 400V for 4 poles, and rated current up to 63A. when people come across the electric shock or the leakage current of the electrical network exceeds the fixed value, the product can cut off the fault current in short period so as to protect person and the equipments, It also can be used in the infrequent starting of the circuit and motors.The circuit breaker is suitable to industry commerce,high-rise building, household and other dinds of places. This product meets the standard of IEC/EN61008-1.

2. Main Technical Parameter

Type

iID

Number of Poles

2P, 4P

Rated current (A)

20, 25, 40, 63

Rated Frequency

50/60Hz

Rated Voltage (V)

2P: AC230/240

4P: AC400/415

Rated Residual Non-peration Current (I△no)(mA)

0.5 I△n

Residual tripping current range

0.5 I△n~ I△n

Rated insulation voltage Ui (V)

500

Rated impulse withstand voltage (V)

6000

Rated breaking capacity

6000

Rated Residual Operating Current (I△n)(mA)

10, 30, 100, 300

Residual Current Off-time

≤ 0.1S

Rated residual current making & breaking capacity

500A(In=25-40A); 630A(In=63A)

Rated conditional short circuit current, Inc

6000A

Ambiemt temperature (℃)

-25~40

Mechanical Life

10000

Electrical life

4000

Degree of protection

IP20

Mount

On 35mm DIN rail

Why Choose Us

Company Profile

Certifications

FAQ

Q1: Are you a circuit breaker factory or a circuit breaker from a trading company?

A1: We are a factory of circuit breaker.

Q2: Can samples be provided for free?
A2: Samples can be provided, but the sample cost should be paid by you. Sample fees will be refunded after further ordering.

Q3: Do you accept customized orders?
A3: Yes. We can provide OEM, ODM services.

Q4: What is the payment term?
A4: We accept TT, 30% deposit and 70% balance before give delivery.

Q5: When is the delivery time?
A5: It usually takes 15-25 days to confirm payment after LY, but the specific time should be based on the order quantity.

Q6: Tell me the standard of package?
A6: Export standard package or special package according to customer requirement.
