Yatai 1550nm High Power WDM 16 Port 23dBm EDFA for CATV HFC PON Edfa
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
1550nm Ftth Catv Pon Edfa 23dBm 16 Ports 32 Ports Optical Amplifier Wdm Edfa
-
FTTH JDSU PUMP 32 Ports1550nm Fiber Optical Amplifier With WDM EDFA
-
16*23dBm Dual Input 2 Power Supply 110V EDFA FTTH 1550 Optical Amplifier EDFA
-
Hot Sale 2u 1550 Edfa 32ports 23dbm WDM Combiner EDFA Pon Catv
-
Hot Sale 1550nm High Power 16 Ports EDFA With Pon For CATV FTTH Amplifier
-
Yatai 1550 WDM CATV FTTH PON EDFA
Product Description
| Operating wavelength | λc | 1540 | 1550 | 1565 | nm |
| Saturated | Po | 13 | ------ | 33 | dBm |
| Input Power | Pi | -3 | ------ | 10 | dBm |
| Gain | G | ------ | ------ | 30 | dB |
| Noise Figure Note2 | NF | ------ | ------ | 6 | dB |
| Output Power Stability | ΔPo | ------ | ±0.05 | ±0.2 | dB |
| Input Isolator | ISOi | 30 | ------ |
------ |
dB |
| Output Isolator | ISOo | 30 | ------ | ------ | dB |
| Input Pump Leakage | PLi | ------ | ------ | -35 | dBm |
| Output Pump Leakage | PLo | ------ | ------ | -45 | dBm |
| Return Loss | RL | ------ | ------ | -45 | dB |
| Polarization Dependent Gain | PDG | ------ | ------ | 0.3 | dB |
| Polarization Mode Dispersion | PMD | ------ | ------ | 0.5 | ps |
| high power edfa inside pump power | |||
| 8 ports | 16 ports | 32 ports | |
| YATAI Brand | 10+10W | 10+10+5W | 20+20+20+20W |
| Other Brand | 10W | 10+10W | 10+10+10+10W |
