Home > Products > Disperser and Mixer > FS4kw-45kw Solvent Based Color Paint High Speed Disperser for Water Based and Oil Based Products
FS4kw-45kw Solvent Based Color Paint High Speed Disperser for Water Based and Oil Based Products
- T/T Credit Card
You May Like
-
11kw High Speed Disperser for Paint and Ink
-
FS Non Explosive High Speed Water-based Paint Cowles Dispersers
-
FS High Speed Paint Twin Shaft Disperser
-
FS22kw High Speed Paint Industrial Mixer Fully Explosion Proof for Both Water-based and Solvent-based Products
-
BF1.5kw-5.5kw High Speed Electrical Disperser Mixer
-
China Hot Sale Fully Explosion Proof High Speed 22kw Disperser Mixer
Product Description
FS4kw-45kw solvent based color paint high speed disperser for water based and oil based products
1.Main Technical Parameters:
Power supply:380V,50Hz,3Phase(can be customized)
| Models | FS4 | FS5.5 | FS7.5 | FS11 | FS15 |
| Principle power | 4KW/5HP | 5.5KW/7.5HP | 7.5KW/10HP | 11KW/15HP | 15KW/20HP |
| Rotational speed |
0-1500 or 0-3000rpm |
||||
| disc size | Φ150 and Φ200mm | Φ200 and Φ250mm | Φ250 and Φ300mm | ||
| Lifting stroke |
900mm |
1000mm |
1200mm | ||
| Pump power |
0.55kw |
0.75kw |
0.75/1.5kw | ||
| Mixing tank capacity | 200L | 250-300L | 400-600L | 500-600L | 800L |
| Weight | 500kg | 600kg | 800kg | 900kg | 1000kg |
| Models | FS18.5 | FS22 | FS30 | FS37 | FS45 |
| Principle power | 18.5KW/25HP | 22KW/30HP | 30KW/40HP | 37KW/50HP | 45KW/60HP |
| Rotational speed |
0-1500 or 0-3000rpm |
||||
| disc size |
Φ300 and Φ350mm |
Φ350 and Φ400mm | |||
| Lifting stroke |
1200mm |
||||
| Pump power |
1.5kw |
2.2kw | |||
| Mixing tank capacity | 1000L | 1200L | 1500-2000L | 2000L-3000L | 3000L-5000L |
| Weight | 1100kg | 1200kg | 1200kg | 1400kg | 1600kg |
3.Remarks:
1)Model of FS22kw,FS30kw,FS37kw and FS45kw can be made double shaft dispersers.
2)The above listed mixing capacity is cauculated as per water medium.
3)The disperser we made can be with power of 132kw.
4)Electric control cabinet can be explosion-proof or non anti-proof.
5)The power supply can be customized.
.




01 Warranty
We ensure one year warranty,life-long service and provides technical support free of charge within warranty.We provide repair service for free(Excluding force majeure damage and artificial damage).
02 Pre-Sale Servic
Our enginner team could provide you with design of complete machine production line.We have our own laboratory in factory and could help clients to do test run of your material,generate lab report and guide your actual production.
03 On-Sale Service
Our factory will manufacture the good quality machines and equipment and test all machines well before dispatch.
04 After-Sale Service
Our engineers will be standby for 24 hours to provide you with prompt solution.We could send technicians to factory to help you install the machines,train your workers to operate and help with the debugging.
05 Spare Parts Service
All wear and easy-broken parts of all machines are available at any time you need.Our enginner will provide you with spare parts scheme before sending the machines to help you know when it is required to change the parts so that to avoid any delay of production.
